คู่มือการทดลองเชิงปรับตัวด้วย Meta Ax: เจาะลึกเวิร์กโฟลว์ Bayesian Optimization ฉบับปฏิบัติ

import importlib, subprocess, sys
def _ensure(module, pip_name=None):
    try:
        importlib.import_module(module)
    except ImportError:
        print(f"Installing {pip_name or module} ...")
        subprocess.check_call([sys.executable, "-m", "pip", "install", "-q", pip_name or module])
_ensure("ax", "ax-platform")
_ensure("sklearn", "scikit-learn")
import logging, warnings, time
import numpy as np
import matplotlib.pyplot as plt
warnings.filterwarnings("ignore")
logging.getLogger("ax").setLevel(logging.WARNING)
from ax.api.client import Client
from ax.api.configs import RangeParameterConfig, ChoiceParameterConfig
from sklearn.datasets import make_classification
from sklearn.ensemble import RandomForestClassifier
from sklearn.model_selection import StratifiedKFold, cross_val_score
np.random.seed(0)

X, y = make_classification(
    n_samples=1400, n_features=20, n_informative=8, n_redundant=4,
    n_classes=3, random_state=0,
)
CV = StratifiedKFold(n_splits=3, shuffle=True, random_state=0)
def evaluate(p):
    n_est, depth = int(p["n_estimators"]), int(p["max_depth"])
    clf = RandomForestClassifier(
        n_estimators=n_est,
        max_depth=depth,
        max_features=float(p["max_features"]),
        min_samples_leaf=int(p["min_samples_leaf"]),
        criterion=p["criterion"],
        ccp_alpha=float(p["ccp_alpha"]),
        n_jobs=-1,
        random_state=0,
    )
    accuracy = cross_val_score(clf, X, y, cv=CV, scoring="accuracy").mean()
    model_size = n_est * depth
    return {"accuracy": float(accuracy), "model_size": float(model_size)}
SEARCH_SPACE = [
    RangeParameterConfig(name="n_estimators", bounds=(50, 300), parameter_type="int"),
    RangeParameterConfig(name="max_depth", bounds=(3, 24), parameter_type="int"),
    RangeParameterConfig(name="max_features", bounds=(0.2, 1.0), parameter_type="float"),
    RangeParameterConfig(name="min_samples_leaf",bounds=(1, 12), parameter_type="int"),
    RangeParameterConfig(name="ccp_alpha", bounds=(1e-5, 1e-1), parameter_type="float", scaling="log"),
    ChoiceParameterConfig(name="criterion", values=["gini", "entropy", "log_loss"],
                          parameter_type="str", is_ordered=False),
]
def run_study(client, total_trials, metric_keys, batch=4):
    records = []
    while len(records) < total_trials:
        trials = client.get_next_trials(max_trials=min(batch, total_trials - len(records)))
        if not trials:
            break
        for idx, params in trials.items():
            full = evaluate(params)
            raw = {k: full[k] for k in metric_keys}
            client.complete_trial(trial_index=idx, raw_data=raw)
            records.append({"trial": idx, "params": params, **full})
    return records

print("\n=== Study 1: constrained single-objective Bayesian optimization ===")
c1 = Client()
c1.configure_experiment(parameters=SEARCH_SPACE, name="rf_constrained")
c1.configure_optimization(objective="accuracy",
                        outcome_constraints=["model_size <= 2500"])
rec1 = run_study(c1, total_trials=24, metric_keys=["accuracy", "model_size"])
best_params, prediction, best_idx, best_arm = c1.get_best_parameterization()
print("\nBest feasible configuration found:")
for k, v in best_params.items():
    print(f" {k:>16}: {v}")
print(" predicted:", prediction)
feasible = [(r["trial"], r["accuracy"]) for r in rec1 if r["model_size"] <= 2500]
best_so_far, cur = [], -np.inf
for _, acc in feasible:
    cur = max(cur, acc); best_so_far.append(cur)
plt.figure(figsize=(7, 4))
plt.plot(range(1, len(best_so_far) + 1), best_so_far, "o-")
plt.xlabel("feasible trial #"); plt.ylabel("best accuracy so far")
plt.title("Study 1 — convergence (subject to model_size <= 2500)")
plt.grid(alpha=0.3); plt.tight_layout(); plt.show()

print("\n=== Study 2: multi-objective (accuracy vs. model_size) ===")
c2 = Client()
c2.configure_experiment(parameters=SEARCH_SPACE, name="rf_multiobjective")
c2.configure_optimization(objective="accuracy, -model_size")
rec2 = run_study(c2, total_trials=28, metric_keys=["accuracy", "model_size"])
try:
    frontier = c2.get_pareto_frontier()
    print(f"Ax identified {len(frontier)} Pareto-optimal configurations.")
except Exception as e:
    frontier = None
    print("get_pareto_frontier unavailable in this version:", e)
acc = np.array([r["accuracy"] for r in rec2])
size = np.array([r["model_size"] for r in rec2])
order = np.argsort(size)
pareto_idx, best_acc = [], -np.inf
for i in order:
    if acc[i] > best_acc:
        best_acc = acc[i]; pareto_idx.append(i)
plt.figure(figsize=(7, 5))
plt.scatter(size, acc, c="lightgray", label="all trials")
plt.scatter(size[pareto_idx], acc[pareto_idx], c="crimson", zorder=3, label="Pareto front")
plt.plot(size[pareto_idx], acc[pareto_idx], "--", c="crimson", alpha=0.6)
plt.xlabel("model_size (lower = cheaper)"); plt.ylabel("accuracy (higher = better)")
plt.title("Study 2 — accuracy vs. model size trade-off")
plt.legend(); plt.grid(alpha=0.3); plt.tight_layout(); plt.show()

print("\n=== Study 3: parameter constraints on a synthetic surface ===")
c3 = Client()
c3.configure_experiment(
    parameters=[
        RangeParameterConfig(name="x1", bounds=(0.0, 1.0), parameter_type="float"),
        RangeParameterConfig(name="x2", bounds=(0.0, 1.0), parameter_type="float"),
    ],
    parameter_constraints=["x1 + x2 <= 1.5"],
    name="constrained_surface",
)
c3.configure_optimization(objective="-dist")
for _ in range(14):
    for idx, p in c3.get_next_trials(max_trials=1).items():
        dist = (p["x1"] - 0.9) ** 2 + (p["x2"] - 0.9) ** 2
        c3.complete_trial(trial_index=idx, raw_data={"dist": float(dist)})
bp, _, _, _ = c3.get_best_parameterization()
print(f"Best point: x1={bp['x1']:.3f}, x2={bp['x2']:.3f}, "
      f"sum={bp['x1'] + bp['x2']:.3f} (constraint: <= 1.5)")
print("Unconstrained optimum would be (0.9, 0.9); Ax respects the boundary.")

print("\n=== Ax built-in analyses for Study 1 ===")
try:
    import plotly.io as pio
    if "google.colab" in sys.modules:
        pio.renderers.default = "colab"
    cards = c1.compute_analyses(display=True)
    print(f"Computed {len(cards)} analysis cards.")
except Exception as e:
    print("Interactive analyses didn't render in this environment:", e)
    print("(The matplotlib plots above already capture the key results.)")
print("\n=== Saving / loading the experiment ===")
try:
    c1.save_to_json_file("ax_study1.json")
    reloaded = Client.load_from_json_file("ax_study1.json")
    print("Saved to ax_study1.json and reloaded successfully.")
    rp, _, _, _ = reloaded.get_best_parameterization()
    print("Best params from reloaded client match:", rp == best_params)
except Exception as e:
    print("JSON persistence API differs in this version:", e)
    print("See: https://ax.dev/docs/recipes/experiment-to-json")
print("\nDone. You optimized a mixed-type search space with constraints, "
      "traced a Pareto frontier, and persisted in the experiment.")
