พยากรณ์ข้อมูล Tabular ด้วย NVIDIA Structured Data Models

import os
import sys
import time
import textwrap
import traceback
import subprocess

RESULTS = {}

def banner(title):
    print("\n" + "=" * 78)
    print(title)
    print("=" * 78)

def section(name):
    def wrap(fn):
        def run(*a, **kw):
            banner(name)
            try:
                out = fn(*a, **kw)
                RESULTS[name] = out if isinstance(out, str) else "ok"
                return out
            except Exception as e:
                RESULTS[name] = f"SKIPPED / FAILED -> {type(e).__name__}: {e}"
                print(f"\n[!] {name} did not complete: {type(e).__name__}: {e}")
                traceback.print_exc(limit=3)
                return None
        return run
    return wrap

banner("1. Install SDM, and the one wheel URL its own error message gets wrong")
subprocess.run([sys.executable, "-m", "pip", "install", "-q", "git+https://github.com/NVIDIA/structured-data-models.git@b982fbf4188ea8db17249fe81338723106100b63"], check=True)

import torch

# The relational sampler needs pyg-lib on CPU. Its wheels are published per MINOR torch version
# (torch-2.14.0+cpu.html), but SDM's own ImportError builds the URL from the exact patch version
# (torch-2.14.1+cpu.html), which is an empty page. Build it from MAJOR.MINOR.0 instead.
major, minor = torch.__version__.split("+")[0].split(".")[:2]
flavour = "cpu" if torch.version.cuda is None else "cu" + torch.version.cuda.replace(".", "")
PYG_INDEX = f"https://data.pyg.org/whl/torch-{major}.{minor}.0+{flavour}.html"
subprocess.run([sys.executable, "-m", "pip", "install", "-q", "pyg-lib", "-f", PYG_INDEX], check=True)

import numpy as np
import pandas as pd
import pyg_lib
import sdm
import sdm.processing as sp
from sklearn.datasets import load_breast_cancer, load_diabetes, make_classification
from sklearn.ensemble import HistGradientBoostingClassifier, HistGradientBoostingRegressor
from sklearn.linear_model import LogisticRegression, RidgeCV
from sklearn.metrics import roc_auc_score
from sklearn.pipeline import make_pipeline
from sklearn.preprocessing import StandardScaler

DEVICE = "cpu"   # verified end to end on CPU; on a T4 runtime set "cuda" for the tabular models
print(f"  sdm {sdm.__version__}  |  torch {torch.__version__}  |  pyg-lib {pyg_lib.__version__}"
      f"  |  device {DEVICE}")
print(f"  pyg-lib wheels from {PYG_INDEX}")
print("\n  One interface over several pretrained structured-data foundation models:")
for name, what, weights in [
    ("TabICLv2", "tabular, in-context learning (ICML '26)", "~110 MB per task head, BSD-3"),
    ("KumoTabular", "tabular, small / medium / large", "small ~110 MB, large ~855 MB, OpenMDW"),
    ("KumoRelational", "multi-table, KumoRFM-2", "~120 MB, OpenMDW"),
    ("TabFM, TimesFM 3", "Google tabular / time series", "6.5 GB / 1.3 GB, non-commercial: not used here"),
]:
    print(f"    {name:18s} {what:42s} {weights}")
print("\n  No model below is trained or fine-tuned. Every prediction is a forward pass that reads")
print("  labelled 'context' rows and answers 'query' rows, like a prompt with examples in it.")

@section("2. Typed tables: what infer_stypes decides, and what a round trip changes")
def typed_tables():
    rng = np.random.default_rng(0)
    words = ["late", "refund", "great", "broken", "fast", "charged", "app", "order", "support", "item"]
    df = pd.DataFrame({
        "ticket_id": np.arange(400),
        "amount": rng.gamma(2, 30, 400).round(2),
        "units": pd.array(rng.integers(1, 5, 400), dtype="Int64"),
        "channel": rng.choice(["web", "app", "phone", None], 400),
        "opened_at": pd.Timestamp("2026-01-01") + pd.to_timedelta(rng.integers(0, 86_400 * 90, 400), unit="s"),
        "comment": [" ".join(rng.choice(words, rng.integers(3, 9))) + f" #{i}" for i in range(400)],
    })
    df.loc[rng.choice(400, 25, replace=False), "units"] = pd.NA

print("  infer_stypes(df) with the defaults, then asking it to look for text and ids:")
    for kw in ({}, {"text": "infer", "id": "infer"}):
        stypes = sdm.infer_stypes(df, **kw)
        print(f"    {str(kw or 'defaults'):34s} {', '.join(f'{c}={s}' for c, s in stypes.items())}")
    print("  With the defaults the free-text comment becomes a 400-level categorical and the id column a")
    print("  number. Both would reach the model as features. Override, or ask: text='infer', id='infer'.")

table = sdm.TableTensor.from_pandas(df, sdm.infer_stypes(df, text="infer", id="infer"))
    print("\n" + textwrap.indent(repr(table), "  "))

back = table.to_pandas()
    print("\n  to_pandas() round trip:")
    for col in df.columns:
        a, b = df[col], back[col]
        if col in ("amount", "units"):
            equal_values = bool(np.allclose(a.astype(float), b.astype(float), equal_nan=True))
        else:
            na_a, na_b = a.isna().to_numpy(), b.isna().to_numpy()
            equal_values = bool((na_a == na_b).all() and
                                (a[~na_a].astype(str).to_numpy() == b[~na_b].astype(str).to_numpy()).all())
        print(f"    {col:10s} {str(a.dtype):16s} -> {str(b.dtype):16s} values preserved: {equal_values}")
    print("  Values survive, including the missing ones; dtypes do not always. Numbers come back float32")
    print("  (the numerical block is one float tensor), nullable Int64 becomes float with NaN, and strings")
    print("  marked categorical come back as a pandas category.")

base = pd.to_datetime(["2026-01-01 08:00:00"] * 3).as_unit("ns")
    whole = pd.DataFrame({"t": base})
    nanos = pd.DataFrame({"t": base + pd.to_timedelta([0, 0, 1], unit="ns")})
    print(f"\n  datetime64[ns], whole seconds:      {sdm.TableTensor.from_pandas(whole, {'t': 'datetime'}).size()} OK")
    try:
        sdm.TableTensor.from_pandas(nanos, {"t": "datetime"})
    except Exception as e:
        print(f"  same column, one value 1 ns later:  {type(e).__name__}: {str(e).split(':')[0]}")
    ok = sdm.TableTensor.from_pandas(nanos.assign(t=nanos.t.dt.floor("us")), {"t": "datetime"})
    print(f"  floor('us') first:                  {ok.size()} OK")
    print("  SDM stores datetimes as int64 microseconds and Arrow refuses any cast that drops a digit. The")
    print("  unit is not the problem; a single value with nanosecond digits fails the whole column.")
    return "6 columns -> 5 typed blocks; text and id need opting in"

typed_tables()

def as_table(df, target):
    return sdm.TableTensor.from_pandas(df, sdm.infer_stypes(df, overrides={target: "categorical"}), device=DEVICE)

@section("3. Zero-training classification: two foundation models vs. two trained baselines")
def zero_training():
    df = load_breast_cancer(as_frame=True).frame.sample(frac=1, random_state=0).reset_index(drop=True)
    table = as_table(df, "target")
    n_ctx = 300
    x_ctx, y_ctx = table[:n_ctx].drop_columns("target"), table[:n_ctx, "target"]
    x_q, y_q = table[n_ctx:].drop_columns("target"), df.target.to_numpy()[n_ctx:]
    rows = []
    for name, make in [("TabICLv2", lambda: sdm.models.TabICLv2(device=DEVICE)),
                       ("KumoTabular (small)", lambda: sdm.models.KumoTabular(size="small", device=DEVICE))]:
        model = make()
        torch.manual_seed(0)
        proba = model(x_context=x_ctx, y_context=y_ctx, x_query=x_q, num_estimators=4).to_pandas()
        rows.append((name, "none", proba.idxmax(axis=1).astype(int).to_numpy(), proba["1"].to_numpy()))
    X, y = df.drop(columns="target"), df.target
    for name, est in [("LogisticRegression", make_pipeline(StandardScaler(), LogisticRegression(max_iter=2000))),
                      ("HistGradientBoosting", HistGradientBoostingClassifier(random_state=0))]:
        est.fit(X[:n_ctx], y[:n_ctx])
        rows.append((name, "fit on 300 rows", est.predict(X[n_ctx:]), est.predict_proba(X[n_ctx:])[:, 1]))
    print(f"  breast cancer: {n_ctx} labelled rows, {len(y_q)} to predict, 30 numeric features\n")
    print(f"  {'model':22s} {'training':16s} {'accuracy':>9s} {'AUC':>7s}")
    for name, training, pred, score in rows:
        print(f"  {name:22s} {training:16s} {np.mean(pred == y_q):9.3f} {roc_auc_score(y_q, score):7.3f}")
    print("\n  The output is itself a TableTensor: one probability column per class, named by label.")
    best = max(rows[:2], key=lambda r: np.mean(r[2] == y_q))
    return f"{best[0]} {np.mean(best[2] == y_q):.3f} accuracy with no training"

zero_training()

@section("4. fit() once, predict() many: the cached context")
def kv_cache():
    df = load_breast_cancer(as_frame=True).frame.sample(frac=1, random_state=0).reset_index(drop=True)
    table = as_table(df, "target")
    x_ctx, y_ctx = table[:400].drop_columns("target"), table[:400, "target"]
    batches = [table[400 + 30 * i: 430 + 30 * i].drop_columns("target") for i in range(5)]
    model = sdm.models.TabICLv2(device=DEVICE)

torch.manual_seed(0)
    t0 = time.time()
    for b in batches:
        model(x_context=x_ctx, y_context=y_ctx, x_query=b, num_estimators=4)
    t_forward = time.time() - t0

torch.manual_seed(0)
    t0 = time.time()
    model.fit(x=x_ctx, y=y_ctx, num_estimators=4)
    t_fit = time.time() - t0
    t0 = time.time()
    for b in batches:
        model.predict(b)
    t_predict = time.time() - t0
    model.clear()
    print("  five batches of 30 query rows against the same 400 context rows:")
    print(f"    forward() x5                      {t_forward:6.2f}s  (context re-encoded every call)")
    print(f"    fit() once + predict() x5         {t_fit + t_predict:6.2f}s  (fit {t_fit:.2f}s, predicts {t_predict:.2f}s)")
    print(f"    per batch: {t_forward / 5:.2f}s vs {t_predict / 5:.2f}s")
    print("\n  fit() encodes the context once into a key/value cache; predict() only runs the queries.")
    print("  clear() frees it. Nothing is learned: fit() here means 'remember these examples'.")
    return f"{t_forward / (t_fit + t_predict):.1f}x faster for five batches"

kv_cache()
``` เพื่อเพิ่มประสิทธิภาพการประมวลผล เราสามารถใช้ฟังก์ชัน `fit()` เพื่อเข้ารหัสบริบทเก็บไว้ในแคช (KV cache) ซึ่งจะช่วยให้การทำ `predict()` ในชุดข้อมูลถัดไปทำได้รวดเร็วขึ้นมาก โดยไม่ต้องเข้ารหัสบริบทเดิมซ้ำทุกครั้ง ขั้นตอนนี้ไม่ใช่การเรียนรู้ของโมเดล แต่เป็นการจดจำตัวอย่างบริบทเพื่อลดภาระการคำนวณ

```python
@section("5. Regression returns a distribution: 999 quantiles, and how honest they are")
def quantile_regression():
    df = load_diabetes(as_frame=True).frame.sample(frac=1, random_state=0).reset_index(drop=True)
    table = sdm.TableTensor.from_pandas(df, sdm.infer_stypes(df), device=DEVICE)
    model = sdm.models.TabICLv2(device=DEVICE)
    torch.manual_seed(0)
    q = model(x_context=table[:300].drop_columns("target"), y_context=table[:300, "target"],
              x_query=table[300:].drop_columns("target"), num_estimators=4).to_pandas()
    y = df.target.to_numpy()[300:]
    print(f"  output: {q.shape[1]} columns {list(q.columns[:3])} ... {list(q.columns[-2:])} per query row")

X, Y = df.drop(columns("target")), df.target
    rmse = lambda p: float(np.sqrt(np.mean((np.asarray(p) - y) ** 2)))
    print(f"\n  {'point prediction':34s} {'RMSE':>7s}")
    print(f"  {'TabICLv2 median (q500), no training':34s} {rmse(q['q500']):7.2f}")
    print(f"  {'RidgeCV, fit on 300 rows':34s} {rmse(RidgeCV().fit(X[:300], Y[:300]).predict(X[300:])):7.2f}")
    print(f"  {'HistGradientBoosting, fit on 300':34s} "
          f"{rmse(HistGradientBoostingRegressor(random_state=0).fit(X[:300], Y[:300]).predict(X[300:])):7.2f}")

print(f"\n  {'interval':12s} {'nominal':>8s} {'empirical coverage':>19s} {'mean width':>11s}")
    coverage = {}
    for lo, hi in [("q250", "q750"), ("q100", "q900"), ("q050", "q950")]:
        nominal = (int(hi[1:]) - int(lo[1:])) / 1000
        coverage[nominal] = float(np.mean((y >= q[lo]) & (y <= q[hi])))
        print(f"  {lo}-{hi:6s} {nominal:8.0%} {coverage[nominal]:19.3f} {np.mean(q[hi] - q[lo]):11.1f}")
    print("\n  The quantiles come from one forward pass over 300 examples, yet the 80% and 90% intervals")
    print("  cover close to 80% and 90% of held-out targets. The 50% band runs a little narrow.")
    return f"median RMSE {rmse(q['q500']):.1f}; 80% interval covers {coverage[0.8]:.1%}"

quantile_regression()

@section("6. Twenty classes from one forward pass")
def many_classes():
    X, y = make_classification(n_samples=800, n_features=12, n_informative=8, n_redundant=2, n_classes=20,
                               n_clusters_per_class=1, class_sep=1.5, random_state=0)
    df = pd.DataFrame(X, columns=[f"f{i}" for i in range(12)])
    df["label"] = [f"c{v:02d}" for v in y]
    table = as_table(df, "label")
    model = sdm.models.TabICLv2(device=DEVICE)
    torch.manual_seed(0)
    t0 = time.time()
    proba = model(x_context=table[:600].drop_columns("label"), y_context=table[:600, "label"],
                  x_query=table[600:].drop_columns("label"), num_estimators=1).to_pandas()
    secs = time.time() - t0
    acc = float(np.mean(proba.idxmax(axis=1).to_numpy() == df.label.to_numpy()[600:]))
    hgb = HistGradientBoostingClassifier(random_state=0).fit(X[:600], y[:600])
    acc_hgb = float(np.mean(hgb.predict(X[600:]) == y[600:]))
    print(f"  20 balanced classes, 600 labelled rows (30 per class), 200 queries")
    print(f"    TabICLv2, no training          {proba.shape[1]} probability columns, accuracy {acc:.3f}  ({secs:.1f}s)")
    print(f"    HistGradientBoosting, trained  accuracy {acc_hgb:.3f}")
    print("\n  The pretrained head has a fixed number of class slots. Past that, SDM splits the problem")
    print("  into error-correcting output codes (sdm.models.ecoc) and recombines the log-probabilities,")
    print("  so the caller still gets one column per label without doing anything.")
    return f"20 classes: {acc:.3f} vs {acc_hgb:.3f} for gradient boosting"

many_classes()

def make_tickets(n=1600, seed=1):
    """Support tickets whose escalation depends on WHEN they were opened and WHAT they say."""
    rng = np.random.default_rng(seed)
    opened = pd.Timestamp("2026-03-02") + pd.to_timedelta(rng.integers(0, 86_400 * 56, n), unit="s")
    neutral = ["order", "item", "delivery", "account", "app", "invoice", "question", "help", "update", "status"]
    hot = ["refund", "broken", "charged", "twice"]
    comments, has_hot = [], []
    for _ in range(n):
        words = list(rng.choice(neutral, rng.integers(4, 9)))
        flag = rng.random() < 0.3
        if flag:
            words.insert(rng.integers(len(words)), rng.choice(hot))
        comments.append(" ".join(words))
        has_hot.append(flag)
    hour, weekend = np.asarray(opened.hour), np.asarray(opened.dayofweek >= 5)
    amount = rng.gamma(2, 40, n).round(2)
    logit = (-1.6 + 2.2 * np.array(has_hot) + 1.4 * ((hour >= 22) | (hour < 6)) + 1.0 * weekend
             + 0.004 * (amount - 80))
    escalated = (rng.random(n) < 1 / (1 + np.exp(-logit))).astype(int)
    return pd.DataFrame({"amount": amount, "channel": rng.choice(["web", "app", "phone"], n),
                         "opened_at": opened, "comment": comments, "escalated": escalated})

@section("7. Recipes: the default one drops your timestamps and your text, and says so once")
def recipes():
    df = make_tickets()
    stypes = sdm.infer_stypes(df, overrides={"escalated": "categorical"}, text="infer")
    table = sdm.TableTensor.from_pandas(df, stypes, device=DEVICE)
    x_ctx, y_ctx = table[:1000].drop_columns("escalated"), table[:1000, "escalated"]
    x_q, y_q = table[1000:].drop_columns("escalated"), df.escalated.to_numpy()[1000:]
    print(f"  columns: {', '.join(f'{c}={s}' for c, s in stypes.items())}")
    print("  escalation is driven by night-time / weekend opening and by words like 'refund'\n")

default = sdm.models.TabICLv2.default_recipe()
    with_calendar = sdm.models.TabICLv2.default_recipe()
    with_calendar.prepend_features(sp.StypeDispatch(
        datetime=sp.AddCalendarFields(["hour", "weekday"], encoding="cyclic")))
    calendar_and_text = sp.StypeDispatch(
        datetime=sp.AddCalendarFields(["hour", "weekday"], encoding="cyclic"),
        text=sp.TFIDF(ngram_range=(1, 1), max_features=64))
    with_both = sdm.models.TabICLv2.default_recipe()
    with_both.prepend_features(calendar_and_text)

model = sdm.models.TabICLv2(device=DEVICE)
    aucs = {}
    for label, recipe in [("default recipe", default),
                          ("+ AddCalendarFields(hour, weekday)", with_calendar),
                          ("+ AddCalendarFields + TFIDF(64 terms)", with_both)]:
        torch.manual_seed(0)
        proba = model(x_context=x_ctx, y_context=y_ctx, x_query=x_q, num_estimators=4, recipe=recipe).to_pandas()
        aucs[label] = roc_auc_score(y_q, proba["1"])
        print(f"  {label:40s} AUC {aucs[label]:.3f}")

print("\n  The default TabICLv2 recipe dispatches on stype and only has branches for categorical and")
    print("  numerical columns, so datetime and text columns never become features. SDM does say so, in")
    print("  the RuntimeWarning above, but it is a warn-once: it fires the first time and is suppressed for")
    print("  the rest of the process. Every later model in the same notebook or service drops those columns")
    print("  in silence. The fix is two processors, prepended to the features:")
    print(textwrap.indent(repr(calendar_and_text), "    "))
    return " -> ".join(f"{v:.3f}" for v in aucs.values()) + " AUC"

recipes()

@section("8. Explaining a prediction: two traps inside the explainer")
def explain():
    rng = np.random.default_rng(2)
    X = rng.normal(size=(500, 8))
    true = {"x0": 2.0, "x3": -1.5, "x5": 1.0}
    logit = sum(w * X[:, int(c[1:])] for c, w in true.items())
    df = pd.DataFrame(X, columns=[f"x{i}" for i in range(8)])
    df["y"] = (rng.random(500) < 1 / (1 + np.exp(-logit))).astype(int)
    table = as_table(df, "y")
    model = sdm.models.TabICLv2(device=DEVICE)
    ctx = dict(x_context=table[:400].drop_columns("y"), y_context=table[:400, "y"])
    x_q = table[400:].drop_columns("y")
    p1 = lambda pred: pred.numerical[..., pred.columns[sdm.Stype.numerical].index("1")]   # P(y=1), by NAME

seen = []
    def peek(pred):
        seen.append(pred.columns[sdm.Stype.numerical])
        return pred.numerical.sum() * 0
    torch.manual_seed(0)
    sdm.explain.GradientExplainer(output=peek).explain(model, x_q, num_estimators=4, **ctx)
    print(f"  num_estimators=4: the output function is called {len(seen)} times, class order per call:")
    print(f"    {seen}")

def only_call(n):
        calls = {"i": 0}
        def f(pred):
            calls["i"] += 1
            return p1(pred) if calls["i"].__eq__(n) else p1(pred) * 0
        return f
    sizes = {}
    for n in (1, len(seen)):
        torch.manual_seed(0)
        g = sdm.explain.GradientExplainer(output=only_call(n)).explain(model, x_q, num_estimators=4, **ctx)
        sizes[n] = float(g.x.to_pandas().abs().mean().mean())
    print(f"\n  Trap 1 - only the LAST estimator is explained. Output function live only on call 1:"
          f" mean |grad| {sizes[1]:.4f};")
    print(f"  live only on call {len(seen)}: {sizes[len(seen)]:.4f}. Each call overwrites the previous result, so")
    print("  with several estimators you get one of them, not their average. Explain with num_estimators=1.")

print("\n  Trap 2 - class order differs per estimator. num_estimators=1, six seeds, P(y=1) selected two ways:")
    print(f"  {'seed':>6s} {'order':>12s}   " + "".join(f"{c + f' ({true[c]:+.1f})':>20s}" for c in true))
    print(f"  {'':6s} {'':12s}   " + "".join(f"{'position / name':>20s}" for _ in true))
    by_name = []
    flipped = name_ok = 0
    for seed in range(6):
        order = []
        def note(pred):
            order.append(pred.columns[sdm.Stype.numerical])
            return pred.numerical.sum() * 0
        torch.manual_seed(seed)
        sdm.explain.GradientExplainer(output=note).explain(model, x_q, num_estimators=1, **ctx)
        res = {}
        for label, fn in (("position", lambda pred: pred.numerical[..., 1]), ("name", p1)):
            torch.manual_seed(seed)
            res[label] = sdm.explain.GradientExplainer(output=fn).explain(
                model, x_q, num_estimators=1, **ctx).x.to_pandas().mean()
        by_name.append(res["name"])
        flipped += any(np.sign(res["position"][c]) != np.sign(w) for c, w in true.items())
        name_ok += all(np.sign(res["name"][c]) == np.sign(w) for c, w in true.items())
        print(f"  {seed:>6d} {str(order[0]):>12s}   " +
              "".join(f"{res['position'][c]:>10.2f} /{res['name'][c]:>7.2f}" for c in true))
    avg = pd.concat(by_name, axis=1).mean(axis=1)
    noise = float(avg.drop(list(true)).abs().max())
    print(f"\n  When the shuffle puts class '1' first, column 1 is P(y=0) and every sign flips. Selecting by")
    print(f"  name gives the right sign on {name_ok}/6 seeds. Averaged over the seeds, by name: " +
          ", ".join(f"{c} {avg[c]:+.2f}" for c in true) + f"; largest noise feature {noise:.2f}.")
    print("  Gradients are with respect to the PREPROCESSED, i.e. standardized, inputs.")
    return f"position flipped signs on {flipped}/6 seeds; name correct on {name_ok}/6; last estimator only"

explain()

def make_shop(seed=0, n_customers=800, n_products=60):
    """Customers, products and a year of orders. Some customers' activity collapses at a random date."""
    rng = np.random.default_rng(seed)
    plans = rng.choice(["basic", "pro"], n_customers, p=[0.7, 0.3])
    customers = pd.DataFrame({"customer_id": np.arange(n_customers),
                              "region": rng.choice(["NA", "EU", "APAC", "LATAM"], n_customers), "plan": plans})
    products = pd.DataFrame({"product_id": np.arange(n_products),
                             "category": rng.choice(["books", "tech", "home", "toys"], n_products),
                             "price": rng.gamma(2.0, 20.0, n_products).round(2)})
    weekly_rate = rng.gamma(1.5, 0.6, n_customers) * np.where(plans == "pro", 1.6, 1.0)
    fade_day = rng.uniform(60, 500, n_customers)
    rows, start = [], pd.Timestamp("2025-01-01")
    for c in range(n_customers):
        t = 0.0
        while True:
            rate = weekly_rate[c] / 7 * (1.0 if t < fade_day[c] else 0.08)
            t += rng.exponential(1 / max(rate, 1e-6))
            if t > 364:
                break
            p = int(rng.integers(n_products))
            rows.append((c, p, start + pd.Timedelta(float(t), unit="D"), float(products.price[p] * rng.integers(1, 4))))
    orders = pd.DataFrame(rows, columns=["customer_id", "product_id", "order_date", "amount"])
    orders.insert(0, "order_id", np.arange(len(orders)))
    orders["order_date"] = orders["order_date"].dt.floor("s")
    return customers, products, orders

def task_rows(customers, orders, cutoff, horizon_days=30):
    """Label: does the customer order again within 30 days of the cutoff?"""
    window = orders[(orders.order_date > cutoff) & (orders.order_date <= cutoff + pd.Timedelta(horizon_days, unit="D"))]
    active = set(window.customer_id)
    return pd.DataFrame({"customer_id": customers.customer_id, "timestamp": cutoff,
                         "label": [int(c in active) for c in customers.customer_id]})

@section("9. A relational database as input: tables, keys, and a time-aware sampler")
def relational_setup():
    customers, products, orders = make_shop()
    data = sdm.RelationalData(
        tables={
            "customers": sdm.TableTensor.from_pandas(customers, {"customer_id": "id", "region": "categorical",
                                                                 "plan": "categorical"}),
            "products": sdm.TableTensor.from_pandas(products, {"product_id": "id", "category": "categorical",
                                                               "price": "numerical"}),
            "orders": sdm.TableTensor.from_pandas(orders, {"order_id": "id", "customer_id": "id", "product_id": "id",
                                                           "order_date": "datetime", "amount": "numerical"}),
        },
        relationships=[
            dict(left_table="orders", left_column="customer_id", right_table="customers", right_column="customer_id"),
            dict(left_table="orders", left_column="product_id", right_table="products", right_column="product_id"),
        ],
    )
    cutoffs_ctx = [pd.Timestamp(d) for d in ("2025-06-01", "2025-07-01", "2025-08-01")]
    cutoff_q = pd.Timestamp("2025-09-15")
    task_df = pd.concat([task_rows(customers, orders, c) for c in cutoffs_ctx + [cutoff_q]], ignore_index=True)
    task = sdm.TableTensor.from_pandas(task_df, {"customer_id": "id", "timestamp": "datetime", "label": "categorical"})
    n_ctx = len(cutoffs_ctx) * len(customers)
    link = dict(task_link={"task_column": "customer_id", "table": "customers", "table_column": "customer_id"},
                num_neighbors=[16, 16], task_time_column="timestamp")

print(f"  {len(customers)} customers, {len(products)} products, {len(orders):,} orders over 2025")
    print("  relationships: orders.customer_id -> customers, orders.product_id -> products")
    print(f"  task: will the customer order in the 30 days after a cutoff? positive rate {task_df.label.mean():.2f}")
    print(f"  context: cutoffs {[str(c.date()) for c in cutoffs_ctx]} ({n_ctx:,} rows); query: {cutoff_q.date()}")

sampler = data.sampler(time_columns={"orders": "order_date"})
    sample, related = sampler(task[:3].drop_columns("label"), **link)
    print("\n  what the sampler hands the model for the first 3 task rows (16 neighbours, then 16 more):")
    for name, tbl in related.tables.items():
        print(f"    {name:10s} {tuple(tbl.size())}")
    latest = related.tables["orders"].to_pandas()["order_date"].max()
    print(f"  latest order the sampler returned: {latest}   task timestamp: {cutoffs_ctx[0]}")
    print("  The sampler walks the foreign keys backwards in time: no order dated after the task row's")
    print("  own timestamp is eligible, so the rows that define the label cannot leak in.")
    globals().update(SHOP=dict(customers=customers, orders=orders, data=data, task=task, task_df=task_df,
                               n_ctx=n_ctx, link=link, cutoffs=cutoffs_ctx + [cutoff_q]))
    return f"{len(orders):,} orders across 3 linked tables"

relational_setup()

def relational_auc(time_columns):
    s = SHOP
    sampler = s["data"].sampler(time_columns=time_columns)
    model = sdm.models.KumoRelational(device=DEVICE)
    torch.manual_seed(0)
    context, related = sampler(s["task"][:s["n_ctx"]], **s["link"])
    model.fit(x=context.drop_columns("label"), y=context["label"], related_tables=related,
              generator=torch.Generator().manual_seed(0))
    query = s["task"][s["n_ctx"] :].drop_columns("label")
    proba = model.predict(*sampler(query, **s["link"])).to_pandas()
    return roc_auc_score(s["task_df"].label.to_numpy()[s["n_ctx"] :], proba["1"])

def history_features(customers, orders, cutoff):
    """The feature engineering a data scientist would write by hand, strictly before the cutoff."""
    past = orders[orders.order_date <= cutoff]
    by_customer = past.groupby("customer_id")
    f = pd.DataFrame({"customer_id": customers.customer_id})
    for days in (30, 90):
        recent = past[past.order_date > cutoff - pd.Timedelta(days, unit="D")].groupby("customer_id")
        f[f"orders_{days}d"] = f.customer_id.map(recent.size()).fillna(0)
        f[f"spend_{days}d"] = f.customer_id.map(recent.amount.sum()).fillna(0)
    f["days_since_last"] = f.customer_id.map((cutoff - by_customer.order_date.max()).dt.days).fillna(999)
    f["orders_total"] = f.customer_id.map(by_customer.size()).fillna(0)
    return f.merge(customers, on="customer_id").drop(columns="customer_id")

def flat_auc(frame_fn):
    s = SHOP
    X = pd.concat([frame_fn(c) for c in s["cutoffs"]], ignore_index=True)
    X["label"] = s["task_df"].label.values
    table = as_table(X, "label")
    model = sdm.models.TabICLv2(device=DEVICE)
    torch.manual_seed(0)
    proba = model(x_context=table[:s["n_ctx"]].drop_columns("label"), y_context=table[:s["n_ctx"], "label"],
                  x_query=table[s["n_ctx"]:].drop_columns("label"), num_estimators=4).to_pandas()
    return roc_auc_score(s["task_df"].label.to_numpy()[s["n_ctx"] :], proba["1"]), list(X.columns[:-1])

@section("10. KumoRelational vs. hand-built features: the same question, three ways")
def relational_vs_features():
    s = SHOP
    results = []
    t0 = time.time()
    auc, cols = flat_auc(lambda c: s["customers"].drop(columns="customer_id"))
    results.append(("TabICLv2 on the customers table only", auc, f"{len(cols)} raw columns", time.time() - t0))
    t0 = time.time()
    auc, cols = flat_auc(lambda c: history_features(s["customers"], s["orders"], c))
    results.append(("TabICLv2 on hand-engineered features", auc, f"{len(cols) - 2} engineered + 2 raw", time.time() - t0))
    t0 = time.time()
    results.append(("KumoRelational on the raw tables", relational_auc({"orders": "order_date"}), "3 raw tables", time.time() - t0))
    print(f"  {'approach':40s} {'AUC':>6s}   {'inputs':22s} {'seconds':>7s}")
    for label, auc, inputs, secs in results:
        print(f"  {label:40s} {auc:6.3f}   {inputs:22s} {secs:7.1f}")
    print("\n  Demographics alone barely beat a coin. Purchase history is where the signal is, and the")
    print("  relational model reaches it without anyone writing orders_30d, spend_90d or days_since_last:")
    print("  it reads the order rows themselves through the keys, as of each task row's timestamp.")
    globals()["REL_AUC"] = results[2][1]
    return (f"customers only {results[0][1]:.3f} / hand-built {results[1][1]:.3f}"
            f" / KumoRelational {results[2][1]:.3f} AUC")

relational_vs_features()

@section("11. The one argument that keeps a relational model honest")
def leakage():
    leaky = relational_auc(None)
    print(f"  KumoRelational with time_columns={{'orders': 'order_date'}}   AUC {REL_AUC:.3f}")
    print(f"  KumoRelational with time_columns=None                     AUC {leaky:.3f}")
    print("\n  Without a time column the sampler is free to return orders placed AFTER the cutoff, which")
    print("  are exactly the orders that define the label. The model is not predicting anymore, it is")
    print("  reading the answer. Nothing errors and the number looks like a breakthrough. On a real")
    print("  database, a relational model that is suspiciously better than your hand-built baseline")
    print("  should be the first thing you re-run with every time column declared.")
    return f"{REL_AUC:.3f} honest vs {leaky:.3f} with future rows visible"

leakage()

banner("SUMMARY")
for name, res in RESULTS.items():
    print(f"  {name:<76s}  {res}")
print("""
What to carry over
 - Declare stypes deliberately: text and id columns are not detected unless you ask, and the
   default TabICLv2 recipe drops datetime and text columns with a warning that fires once.
 - In an explainer output function, select classes by name, never by position.
 - Every table with a time column goes in time_columns. A relational model that is not time-aware
   is a leakage detector, not a forecaster.
Where to go next
 - Fine-tuning: examples/tabular/finetune.py disables the output recipe and trains on raw logits.
 - Real relational benchmarks: examples/relational/rel_bench.py runs KumoRelational on RelBench.
 - On a T4 runtime, set DEVICE = "cuda" for the tabular models; cudf keeps dataframe work on GPU.
 - Docs: nvidia.github.io/structured-data-models    Code: github.com/NVIDIA/structured-data-models
""")
``` โดยสรุป Structured Data Models ของ NVIDIA ให้ผลลัพธ์ที่น่าประทับใจทั้งในแง่ความแม่นยำและการใช้งานโดยไม่ต้องเทรนใหม่ อย่างไรก็ตาม ผู้ใช้ต้องระวังการตั้งค่าเริ่มต้นที่อาจตัดข้อมูลสำคัญทิ้งหรือทำให้เกิดข้อมูลรั่วไหล การประกาศประเภทข้อมูลอย่างเจาะจงและการจัดการคอลัมน์เวลาอย่างถูกต้องคือกุญแจสำคัญในการนำไลบรารีนี้ไปใช้งานจริงให้ประสบความสำเร็จ
