เจาะลึก Cosmos-Framework จาก NVIDIA: สร้างโมเดลโลกจำลอง Mixture-of-Transformers บน Colab

import os, sys, json, time, math, textwrap, subprocess, shutil, platform
from pathlib import Path
def rule(title=""):
   line = "=" * 86
   print("\n" + line + ("\n  " + title if title else "") + "\n" + line)
def spark(vals, width=60):
   """Tiny ASCII sparkline for a 1-D sequence (works with no plotting libs)."""
   if not vals: return ""
   blocks = "▁▂▃▄▅▆▇█"
   lo, hi = min(vals), max(vals)
   rng = (hi - lo) or 1.0
   step = max(1, len(vals) // width)
   s = "".join(blocks[min(len(blocks) - 1, int((v - lo) / rng * (len(blocks) - 1)))]
               for v in vals[::step])
   return s
rule("SECTION 0 — Environment probe: what you have vs. what Cosmos 3 actually needs")
IN_COLAB = "google.colab" in sys.modules
print(f"Running inside Google Colab : {IN_COLAB}")
print(f"Python                      : {platform.python_version()}  ({platform.system()})")
try:
   import torch
except ModuleNotFoundError:
   print("torch not found — installing CPU build (a few seconds)...")
   subprocess.run([sys.executable, "-m", "pip", "install", "-q", "torch"], check=False)
   import torch
print(f"PyTorch                     : {torch.__version__}")
CUDA_OK = torch.cuda.is_available()
DEVICE = torch.device("cuda" if CUDA_OK else "cpu")
gpu_name, gpu_mem_gb, cc = "None (CPU)", 0.0, (0, 0)
if CUDA_OK:
   p = torch.cuda.get_device_properties(0)
   gpu_name = p.name
   gpu_mem_gb = p.total_memory / 1024**3
   cc = torch.cuda.get_device_capability(0)
   print(f"CUDA build                  : {torch.version.cuda}")
   print(f"GPU                         : {gpu_name}")
   print(f"GPU memory                  : {gpu_mem_gb:.1f} GiB")
   print(f"Compute capability          : sm_{cc[0]}{cc[1]}")
try:
   free_gb = shutil.disk_usage('/').free / 1024**3
   print(f"Free disk                   : {free_gb:.0f} GiB")
except Exception:
   free_gb = 0.0
AMPERE = cc[0] >= 8
reqs = [
   ("GPU architecture", "Ampere+ (sm_80+, A100/RTX30xx)",  "OK" if AMPERE else "TOO OLD (T4=sm_75)"),
   ("GPU memory",       ">=80 GiB for Nano-16B (single H100)", "OK" if gpu_mem_gb >= 79 else f"{gpu_mem_gb:.0f} GiB — insufficient"),
   ("CUDA toolkit",     ">=12.8",                            "check" ),
   ("Free disk",        "~150 GiB first run (~1 TB HF cache)", "OK" if free_gb >= 150 else f"{free_gb:.0f} GiB — insufficient"),
   ("Attention kernels","FlashAttn-3 (Hopper) / FA2 (Ampere)", "needs Ampere+"),
]
print("\n  Can this machine run the REAL Cosmos 3 checkpoints?")
print("  " + "-" * 82)
print(f"  {'Requirement':<18}{'Cosmos 3 needs':<38}{'You have'}")
print("  " + "-" * 82)
for k, need, have in reqs:
   print(f"  {k:<18}{need:<38}{have}")
print("  " + "-" * 82)
VERDICT = AMPERE and gpu_mem_gb >= 79 and free_gb >= 150
print(f"  VERDICT: {'This machine could attempt Nano-16B.' if VERDICT else 'NO — real Cosmos 3 inference is not possible here. Educational path below.'}")

REPO = "https://github.com/NVIDIA/cosmos-framework.git"
DST = Path("/content/cosmos-framework") if Path("/content").exists() else Path("cosmos-framework")
cloned = False
try:
   if not DST.exists():
       print(f"Shallow-cloning {REPO} ...")
       subprocess.run(["git", "clone", "--depth", "1", REPO, str(DST)],
                      check=True, capture_output=True, text=True, timeout=180)
   cloned = DST.exists()
except Exception as e:
   print(f"(Clone skipped/failed — offline is fine, tutorial continues.) {e}")
if cloned:
   print(f"Repo at: {DST}\n")
   pkg = DST / "cosmos_framework"
   if pkg.exists():
       print("cosmos_framework/ subpackages (the real code layout):")
       for child in sorted(pkg.iterdir()):
           if child.is_dir() and not child.name.startswith(("_", ".")):
               n_py = len(list(child.rglob("*.py")))
               print(f"   • {child.name:<20} ({n_py:>3} .py files)")
   example = DST / "inputs" / "omni" / "t2v.json"
   if example.exists():
       print(f"\nReal example input spec  ({example.relative_to(DST)}):")
       print(textwrap.indent(example.read_text().strip(), "   "))
else:
   print("Proceeding without a local clone (we already extracted the real schema/CLI).")
print("""
Real CLI surface (docs/inference.md):
  Single GPU : python -m cosmos_framework.scripts.inference \\
                   --parallelism-preset=latency -i "inputs/omni/t2v.json" \\
                   -o outputs/omni_nano --checkpoint-path Cosmos3-Nano --seed 0
  Multi  GPU : torchrun --nproc-per-node=8 -m cosmos_framework.scripts.inference \\
                   --parallelism-preset=throughput -i "inputs/omni/*.json" \\
                   -o outputs/omni_super --checkpoint-path Cosmos3-Super --seed 0
  Models     : Cosmos3-Nano (16B, all modes) | Cosmos3-Super (65B, t2i/t2v/i2v)
  Modes      : text2image · text2video · image2video · video2video ·
               forward_dynamics · inverse_dynamics · policy
  Parallelism: FSDP dp-shard / dp-replicate · context (cp) · CFG (cfgp)
               presets {latency, throughput}
  Guardrails : Cosmos-Guardrail1 + Qwen3Guard-Gen-0.6B + RetinaFace (on by default)
""")
rule("SECTION 2 — Omnimodal Mixture-of-Transformers (MoT) world model — the idea")
print(r"""
Cosmos 3 unifies language, image, video, audio and ACTION in ONE model. The key trick
is a Mixture-of-Transformers: every modality is turned into tokens placed on a SINGLE
interleaved sequence; SELF-ATTENTION is SHARED across all modalities (so vision can be
conditioned on text, actions on vision, etc.), but each token is processed by a
MODALITY-SPECIFIC expert feed-forward block ("Mixture-of-Transformers" routing).
       text tokens        vision tokens          action tokens
       [t0 t1 t2 ...]     [v0 v1 v2 ...]         [a0 a1 ...]
            \                   |                     /
             \                  |                    /
              +----------- one sequence -----------+
                             |
                ┌─────────── shared causal self-attention (RoPE) ───────────┐
                │  every token attends to all earlier tokens, ANY modality  │
                └───────────────────────────────────────────────────────────┘
                             |
                route each token to its modality's EXPERT FFN (SwiGLU):
                   text→Expert0     vision→Expert1     action→Expert2
                             |
                per-modality heads:  next-token / next-latent / next-action
Physical-AI modes fall right out of this one model:
  text2video      = generate the vision-token stream from a text prompt
  image2video     = condition vision stream on a first frame + text
  forward_dynamics= given frames + ACTIONS, roll future frames forward   (a world model)
  inverse_dynamics= given frames, infer the ACTIONS that caused them
  policy          = given an observation + goal, emit ACTIONS (+ imagined rollout)
Below we build a faithful ~4M-param miniature of exactly this and train it live.
(The real model uses flow-matching/diffusion for the continuous vision stream; our toy
uses a simple MSE next-latent objective so it trains in seconds — the ROUTING and
SHARED-ATTENTION structure are the same.)
""")

import torch.nn as nn
import torch.nn.functional as F
from dataclasses import dataclass
torch.manual_seed(0)
@dataclass
class Cfg:
   d_model:   int = 192
   n_head:    int = 6
   n_layer:   int = 4
   ffn_mult:  int = 2
   n_mod:     int = 3
   text_vocab:int = 16
   vis_dim:   int = 8
   act_dim:   int = 4
   Lt:        int = 8
   Lv:        int = 8
   La:        int = 6
cfg = Cfg()
class RMSNorm(nn.Module):
   def __init__(self, d, eps=1e-6):
       super().__init__(); self.w = nn.Parameter(torch.ones(d)); self.eps = eps
   def forward(self, x):
       return self.w * x * torch.rsqrt(x.pow(2).mean(-1, keepdim=True) + self.eps)
def build_rope(T, hd, device, base=10000.0):
   pos  = torch.arange(T, device=device, dtype=torch.float32)[:, None]
   idx  = torch.arange(0, hd, 2, device=device, dtype=torch.float32)[None, :]
   freq = 1.0 / (base ** (idx / hd))
   ang  = pos * freq
   cos  = torch.cos(ang).repeat(1, 2)[None, None]
   sin  = torch.sin(ang).repeat(1, 2)[None, None]
   return cos, sin
def rotate_half(x):
   hd = x.shape[-1]; x1, x2 = x[..., :hd // 2], x[..., hd // 2:]
   return torch.cat([-x2, x1], -1)
def apply_rope(q, k, cos, sin):
   return q * cos + rotate_half(q) * sin, k * cos + rotate_half(k) * sin
class Attention(nn.Module):
   """Shared cross-modal causal self-attention with rotary embeddings."""
   def __init__(self, c: Cfg):
       super().__init__()
       self.H, self.hd = c.n_head, c.d_model // c.n_head
       self.qkv  = nn.Linear(c.d_model, 3 * c.d_model, bias=False)
       self.proj = nn.Linear(c.d_model, c.d_model, bias=False)
   def forward(self, x, cos, sin, mask):
       B, T, D = x.shape
       q, k, v = self.qkv(x).chunk(3, -1)
       q = q.view(B, T, self.H, self.hd).transpose(1, 2)
       k = k.view(B, T, self.H, self.hd).transpose(1, 2)
       v = v.view(B, T, self.H, self.hd).transpose(1, 2)
       q, k = apply_rope(q, k, cos, sin)
       att = (q @ k.transpose(-2, -1)) / math.sqrt(self.hd)
       att = att.masked_fill(mask, float("-inf")).softmax(-1)
       o = (att @ v).transpose(1, 2).reshape(B, T, D)
       return self.proj(o)
class Expert(nn.Module):
   """A per-modality SwiGLU feed-forward 'transformer expert'."""
   def __init__(self, d, mult):
       super().__init__(); h = d * mult
       self.w1 = nn.Linear(d, h, bias=False)
       self.w3 = nn.Linear(d, h, bias=False)
       self.w2 = nn.Linear(h, d, bias=False)
   def forward(self, x):
       return self.w2(F.silu(self.w1(x)) * self.w3(x))
class MoTBlock(nn.Module):
   """Shared attention + Mixture-of-Transformers (per-modality expert) routing."""
   def __init__(self, c: Cfg):
       super().__init__()
       self.attn_norm = RMSNorm(c.d_model)
       self.attn      = Attention(c)
       self.ffn_norm  = nn.ModuleList([RMSNorm(c.d_model) for _ in range(c.n_mod)])
       self.experts   = nn.ModuleList([Expert(c.d_model, c.ffn_mult) for _ in range(c.n_mod)])
   def forward(self, x, cos, sin, mask, mod_id):
       x = x + self.attn(self.attn_norm(x), cos, sin, mask)
       out = torch.zeros_like(x)
       for i, exp in enumerate(self.experts):
           sel = (mod_id == i).view(1, -1, 1).to(x.dtype)
           out = out + sel * exp(self.ffn_norm[i](x))
       return x + out
class OmniMoT(nn.Module):
   def __init__(self, c: Cfg):
       super().__init__(); self.c = c
       self.text_emb = nn.Embedding(c.text_vocab, c.d_model)
       self.vis_in   = nn.Linear(c.vis_dim, c.d_model)
       self.act_in   = nn.Linear(c.act_dim, c.d_model)
       self.mod_emb  = nn.Embedding(c.n_mod, c.d_model)
       self.blocks   = nn.ModuleList([MoTBlock(c) for _ in range(c.n_layer)])
       self.norm     = RMSNorm(c.d_model)
       self.text_head = nn.Linear(c.d_model, c.text_vocab, bias=False)
       self.vis_head  = nn.Linear(c.d_model, c.vis_dim,  bias=False)
       self.act_head  = nn.Linear(c.d_model, c.act_dim,  bias=False)
       ids = torch.cat([torch.zeros(c.Lt), torch.ones(c.Lv), torch.full((c.La,), 2)]).long()
       self.register_buffer("mod_id", ids, persistent=False)
   def forward(self, text, vis, act):
       c = self.c
       x = torch.cat([self.text_emb(text), self.vis_in(vis), self.act_in(act)], 1)
       x = x + self.mod_emb(self.mod_id)[None]
       B, T, D = x.shape
       cos, sin = build_rope(T, D // c.n_head, x.device)
       mask = torch.triu(torch.ones(T, T, dtype=torch.bool, device=x.device), 1)[None, None]
       for blk in self.blocks:
           x = blk(x, cos, sin, mask, self.mod_id)
       x = self.norm(x)
       ht = self.text_head(x[:, :c.Lt])
       hv = self.vis_head(x[:, c.Lt:c.Lt + c.Lv])
       ha = self.act_head(x[:, c.Lt + c.Lv:])
       return ht, hv, ha
model = OmniMoT(cfg).to(DEVICE)
n_params = sum(p.numel() for p in model.parameters())
print(f"Model built: OmniMoT  |  {n_params/1e6:.2f}M params  |  {cfg.n_layer} MoT blocks "
     f"x {cfg.n_mod} experts  |  device={DEVICE}")

K = 4
g = torch.Generator().manual_seed(1)
# Training On Synthetic Data
TEXT_TRANS = torch.stack([torch.softmax(torch.randn(cfg.text_vocab, cfg.text_vocab, generator=g), -1)
                         for _ in range(K)])
VIS_DYN = torch.stack([0.9 * torch.linalg.qr(torch.randn(cfg.vis_dim, cfg.vis_dim, generator=g))[0]
                      for _ in range(K)])
ACT_MAP = torch.randn(cfg.act_dim, cfg.vis_dim, generator=g) * 0.5
def make_batch(B):
   codes = torch.randint(0, K, (B,), generator=g)
   text = torch.zeros(B, cfg.Lt, dtype=torch.long)
   text[:, 0] = torch.randint(0, cfg.text_vocab, (B,), generator=g)
   for t in range(1, cfg.Lt):
       probs = TEXT_TRANS[codes, text[:, t-1]]
       text[:, t] = torch.multinomial(probs, 1, generator=g).squeeze(1)
   vis = torch.zeros(B, cfg.Lv, cfg.vis_dim)
   vis[:, 0] = torch.randn(B, cfg.vis_dim, generator=g)
   for t in range(1, cfg.Lv):
       vis[:, t] = torch.einsum("bij,bj->bi", VIS_DYN[codes], vis[:, t-1]) \
                   + 0.02 * torch.randn(B, cfg.vis_dim, generator=g)
   vis_state = vis.mean(1)
   act = torch.zeros(B, cfg.La, cfg.act_dim)
   for t in range(cfg.La):
       act[:, t] = (ACT_MAP @ (vis_state * (0.8 ** t)).T).T \
                   + 0.02 * torch.randn(B, cfg.act_dim, generator=g)
   return text.to(DEVICE), vis.to(DEVICE), act.to(DEVICE), codes
def loss_fn(model, text, vis, act):
   ht, hv, ha = model(text, vis, act)
   l_text = F.cross_entropy(ht[:, :-1].reshape(-1, cfg.text_vocab), text[:, 1:].reshape(-1))
   l_vis  = F.mse_loss(hv[:, :-1], vis[:, 1:])
   l_act  = F.mse_loss(ha[:, :-1], act[:, 1:])
   return l_text + l_vis + l_act, (l_text.item(), l_vis.item(), l_act.item())
opt = torch.optim.AdamW(model.parameters(), lr=3e-3, weight_decay=0.01)
STEPS, BATCH = 400, 64
hist, t0 = [], time.time()
print(f"\nTraining for {STEPS} steps (batch={BATCH})...")
model.train()
for step in range(1, STEPS + 1):
   text, vis, act, _ = make_batch(BATCH)
   loss, parts = loss_fn(model, text, vis, act)
   opt.zero_grad(); loss.backward()
   torch.nn.utils.clip_grad_norm_(model.parameters(), 1.0)
   opt.step()
   hist.append(loss.item())
   if step % 50 == 0 or step == 1:
       print(f"  step {step:4d}  total {loss.item():6.3f}  "
             f"| text {parts[0]:5.3f}  vision {parts[1]:6.4f}  action {parts[2]:6.4f}")
print(f"Trained in {time.time()-t0:.1f}s  |  loss {hist[0]:.3f} -> {hist[-1]:.3f}")
print("  loss curve: " + spark(hist))
try:
   import matplotlib.pyplot as plt
   plt.figure(figsize=(7, 3))
   plt.plot(hist); plt.title("OmniMoT training loss"); plt.xlabel("step"); plt.ylabel("loss")
   plt.grid(alpha=0.3); plt.tight_layout(); plt.show()
except Exception:
   pass

def rollout(model, text, vis_prefix, act, n_future):
   """Predict n_future vision latents autoregressively from a vision prefix."""
   model.eval()
   vis = vis_prefix.clone()
   preds = []
   for _ in range(n_future):
       pad = cfg.Lv - vis.shape[1]
       vis_in = vis if pad <= 0 else torch.cat(
           [vis, vis[:, -1:].repeat(1, pad, 1)], 1)
       _, hv, _ = model(text, vis_in[:, :cfg.Lv], act)
       nxt = hv[:, min(vis.shape[1], cfg.Lv) - 1:min(vis.shape[1], cfg.Lv)]
       preds.append(nxt)
       vis = torch.cat([vis, nxt], 1)
   return torch.cat(preds, 1)
text, vis, act, codes = make_batch(4)
prefix_len, n_future = 3, 5
pred = rollout(model, text, vis[:, :prefix_len], act, n_future)
gt = vis[:, prefix_len-1:prefix_len].clone()
true_steps = [gt]
cur = gt
for _ in range(n_future):
   cur = torch.einsum("bij,bj->bi", VIS_DYN[codes].to(DEVICE), cur[:, -1]).unsqueeze(1)
   true_steps.append(cur)
gt_traj = torch.cat(true_steps[1:], 1)
err = F.mse_loss(pred, gt_traj).item()
print(f"Rolled out {n_future} future vision latents for {text.shape[0]} scenes.")
print(f"Imagined-vs-true-physics MSE : {err:.4f}   (a small number = it learned the dynamics)")
print(f"Example (scene 0) latent[0] over time:")
print(f"   predicted : {pred[0,:,0].detach().cpu().numpy().round(3).tolist()}")
print(f"   true      : {gt_traj[0,:,0].detach().cpu().numpy().round(3).tolist()}")

specs = {
   "t2i.json": {
       "model_mode": "text2image",
       "prompt": "a robot arm neatly stacking three wooden blocks on a lab bench, cinematic",
       "resolution": "480", "aspect_ratio": "16,9", "num_frames": 1, "seed": 0,
   },
   "t2v.json": {
       "model_mode": "text2video",
       "prompt": "first-person view of a warehouse AMR navigating around pallets, smooth motion",
       "resolution": "480", "aspect_ratio": "16,9", "fps": 16, "num_frames": 121, "seed": 0,
   },
   "t2vs.json": {
       "model_mode": "text2video", "enable_sound": True,
       "prompt": "rain falling on a tin roof at night, distant thunder, puddles rippling",
       "resolution": "480", "fps": 16, "num_frames": 121, "seed": 0,
   },
   "i2v.json": {
       "model_mode": "image2video",
       "prompt": "the camera slowly pushes in as steam rises from the cup",
       "vision_path": "assets/first_frame.jpg",
       "resolution": "480", "fps": 16, "num_frames": 121, "seed": 0,
   },
   "action_forward_dynamics_robot.json": {
       "model_mode": "forward_dynamics",
       "domain_name": "bridge_orig_lerobot", "view_point": "ego_view",
       "vision_path": "assets/obs.mp4", "action_path": "assets/actions.json",
       "action_chunk_size": 12, "image_size": 256, "seed": 0,
   },
   "action_policy_robot.json": {
       "model_mode": "policy",
       "domain_name": "bridge_orig_lerobot", "view_point": "ego_view",
       "vision_path": "assets/obs.mp4", "prompt": "pick up the red cube and place it in the bowl",
       "action_chunk_size": 12, "image_size": 256, "seed": 0,
   },
}
spec_dir = (Path("/content") if Path("/content").exists() else Path(".")) / "cosmos_inputs"
spec_dir.mkdir(exist_ok=True)
for name, obj in specs.items():
   (spec_dir / name).write_text(json.dumps(obj, indent=2))
print(f"Wrote {len(specs)} ready-to-use, schema-correct input specs to: {spec_dir}\n")
print("Example — text2video spec (inputs/omni/t2v.json):")
print(textwrap.indent(json.dumps(specs["t2v.json"], indent=2), "   "))
print("""
EXACT launch commands (run these where you have the hardware; do NOT expect them on Colab):
 # Single 80GB H100 — Nano only, latency preset (lowest per-sample wall time)
 python -m cosmos_framework.scripts.inference \\
     --parallelism-preset=latency \\
     -i "cosmos_inputs/t2v.json" -o outputs/nano \\
     --checkpoint-path Cosmos3-Nano --seed 0
 # Whole batch on 8x H100 — Nano, throughput preset
 torchrun --nproc-per-node=8 -m cosmos_framework.scripts.inference \\
     --parallelism-preset=throughput \\
     -i "cosmos_inputs/*.json" -o outputs/nano_batch \\
     --checkpoint-path Cosmos3-Nano --seed 0
 # Cosmos3-Super (65B) — must shard across GPUs (does NOT fit on one H100)
 torchrun --nproc-per-node=4 -m cosmos_framework.scripts.inference \\
     --parallelism-preset=throughput --dp-shard-size=4 --dp-replicate-size=1 \\
     --cp-size=1 --cfgp-size=1 \\
     -i "cosmos_inputs/t2v.json" -o outputs/super \\
     --checkpoint-path Cosmos3-Super --seed 0
 # Tight on memory? climb this ladder (from docs/faq.md):
 export PYTORCH_CUDA_ALLOC_CONF=expandable_segments:True
 ... --offload-guardrail-models         # keep guardrails on CPU between calls
 ... --no-guardrails                     # (last resort; disables safety filters)
""")
print("  Model / hardware reality table")
print("  " + "-" * 82)
print(f"  {'Model':<16}{'Params':<9}{'Fits on 1x H100 80GB?':<24}{'Recommended':<18}")
print("  " + "-" * 82)
for m, pr, one, rec in [
   ("Cosmos3-Nano",  "16B", "Yes (latency preset)",   "1-8x H100"),
   ("Cosmos3-Super", "65B", "No — must shard (FSDP)",  "4-8x H100"),
]:
   print(f"  {m:<16}{pr:<9}{one:<24}{rec:<18}")
print("  " + "-" * 82)
