NVIDIA srt-slurm: เวิร์กโฟลว์เบนช์มาร์ก LLM แบบกระจายด้วย SLURM Recipes และ Pareto Analysis

import os, sys, subprocess, textwrap, json, shutil, importlib
from pathlib import Path
def run(cmd, check=True, quiet=False):
"""Run a shell command, stream output."""
print(f"\n$ {cmd}")
r = subprocess.run(cmd, shell=True, text=True, capture_output=True)
out = (r.stdout or "") + (r.stderr or "")
if not quiet:
print(out[-6000:])
if check and r.returncode != 0:
raise RuntimeError(f"Command failed ({r.returncode}): {cmd}")
return out
def section(title):
print("\n" + "═"*78 + f"\n {title}\n" + "═"*78)
section("1. Install srt-slurm")
REPO = Path("/content/srt-slurm") if Path("/content").exists() else Path.cwd()/"srt-slurm"
if not REPO.exists():
run(f"git clone --depth 1 https://github.com/NVIDIA/srt-slurm.git {REPO}", quiet=True)
run(f"{sys.executable} -m pip install -q -e {REPO}", quiet=True)
sys.path.insert(0, str(REPO / "src"))
importlib.invalidate_caches()
os.chdir(REPO)
run("srtctl --help")

section("2. Repository architecture")
print(textwrap.dedent("""
src/srtctl/
cli/ submit.py (apply/dry-run/preflight/monitor), do_sweep, interactive
core/ schema.py (typed config), sweep.py, slurm.py (sbatch gen),
validation.py, health.py, topology.py, fingerprint.py
backends/ sglang.py, trtllm.py, vllm.py, mocker.py ← engine adapters
frontends/ Dynamo / router frontends
templates/ Jinja2 → sbatch + orchestrator scripts
recipes/ ready-made benchmarks per platform (gb200-fp4, h100, b200-fp8,
qwen3-32b, dsv4-pro, mocker smoke tests, ...)
analysis/ srtlog (log parsers) + Streamlit dashboard (Pareto, latency...)
docs/ sweeps.md, profiling.md, analyzing.md, config-reference.md
"""))
for d in ["recipes", "docs"]:
print(f"{d}/ →", ", ".join(sorted(p.name for p in (REPO/d).iterdir()))[:300])
section("3. Cluster configuration (srtslurm.yaml)")
(REPO/"srtslurm.yaml").write_text(textwrap.dedent("""\
cluster: "colab-demo"
default_account: "demo-account"
default_partition: "gpu"
default_time_limit: "01:00:00"
gpus_per_node: 4
use_gpus_per_node_directive: true
use_segment_sbatch_directive: true
containers:
dynamo-sglang: "/containers/dynamo-sglang.sqsh"
lmsysorg+sglang+v0.5.5.post2.sqsh: "/containers/sglang-v0.5.5.sqsh"
model_paths:
deepseek-r1: "/models/DeepSeek-R1"
"""))
print((REPO/"srtslurm.yaml").read_text())

section("4. Dry-run: mocker smoke test → generated sbatch script")
run("srtctl dry-run -f recipes/mocker/agg.yaml", check=False)
section("5. Custom disaggregated recipe (prefill/decode split)")
(REPO/"my-disagg.yaml").write_text(textwrap.dedent("""\
name: "colab-disagg-demo"
model:
path: "deepseek-r1"
container: "lmsysorg+sglang+v0.5.5.post2.sqsh"
precision: "fp8"
resources:
gpu_type: "gb200"
gpus_per_node: 4
prefill_nodes: 1
decode_nodes: 2
prefill_workers: 1
decode_workers: 2
backend:
prefill_environment: { PYTHONUNBUFFERED: "1" }
decode_environment: { PYTHONUNBUFFERED: "1" }
sglang_config:
prefill:
served-model-name: "deepseek-ai/DeepSeek-R1"
model-path: "/model/"
trust-remote-code: true
kv-cache-dtype: "fp8_e4m3"
tensor-parallel-size: 4
disaggregation-mode: "prefill"
decode:
served-model-name: "deepseek-ai/DeepSeek-R1"
model-path: "/model/"
trust-remote-code: true
kv-cache-dtype: "fp8_e4m3"
tensor-parallel-size: 4
disaggregation-mode: "decode"
benchmark:
type: "sa-bench"
isl: 1024
osl: 1024
concurrencies: [64, 128, 256]
req_rate: "inf"
"""))
run("srtctl dry-run -f my-disagg.yaml", check=False)

section("6. Parameter sweep (grid search) — dry-run + expansion on disk")
run("srtctl dry-run -f examples/example-sweep.yaml", check=False)
sweep_dirs = sorted((REPO/"dry-runs").glob("example-sweep_sweep_*"))
if sweep_dirs:
latest = sweep_dirs[-1]
print("Per-job configs generated by the sweep expander:")
for p in sorted(latest.rglob("config.yaml")):
print(" ", p.relative_to(REPO))
section("7. Programmatic use of srtctl's Python API")
import yaml
from srtctl.core.config import load_config
from srtctl.core.sweep import generate_sweep_configs, expand_template
from srtctl.core.schema import BenchmarkType, Precision, GpuType
cfg = load_config("my-disagg.yaml")
print(f"Loaded : {cfg.name}")
print(f"Model : {cfg.model.path} ({cfg.model.precision}) on {cfg.resources.gpu_type}")
print(f"Layout : {cfg.resources.prefill_nodes}P + {cfg.resources.decode_nodes}D nodes, "
f"{cfg.resources.gpus_per_node} GPUs/node")
print(f"Bench : {cfg.benchmark.type} isl={cfg.benchmark.isl} osl={cfg.benchmark.osl} "
f"concurrencies={cfg.benchmark.concurrencies}")
print(f"Enums : benchmarks={[b.value for b in BenchmarkType]}")
print(f" precisions={[p.value for p in Precision]}, gpus={[g.value for g in GpuType]}")
raw_sweep = yaml.safe_load(Path("examples/example-sweep.yaml").read_text())
jobs = generate_sweep_configs(raw_sweep)
print(f"\nSweep expands to {len(jobs)} jobs:")
for job_cfg, params in jobs:
pf = job_cfg["backend"]["sglang_config"]["prefill"]
print(f" {params} → chunked-prefill-size={pf['chunked-prefill-size']}, "
f"max-total-tokens={pf['max-total-tokens']}")
print("\nTemplate substitution:",
expand_template({"flag": "{x}", "n": "{y}"}, {"x": 4096, "y": 2}))

section("8. Analysis: Pareto frontier from (simulated) benchmark results")
import numpy as np, matplotlib.pyplot as plt
rng = np.random.default_rng(0)
def simulate(variant, base_tps, base_itl):
rows = []
tps_gpu = base_tps * c / (c + 90) * rng.uniform(.97, 1.03)
itl = base_itl * (1 + c/220) * rng.uniform(.97, 1.03)
row_data = {"variant": variant, "concurrency": c,
"tok_s_gpu": tps_gpu, "itl_ms": itl}
return row_data
results = []
for c in [64, 128, 256]:
results.append({"variant": "chunked=4096", "concurrency": c, "tok_s_gpu": 260 * c / (c + 90), "itl_ms": 9.5 * (1 + c/220)})
results.append({"variant": "chunked=8192", "concurrency": c, "tok_s_gpu": 300 * c / (c + 90), "itl_ms": 11.5 * (1 + c/220)})

print(json.dumps(results[:3], indent=2), "...")
plt.figure(figsize=(8, 5))
for variant in ("chunked=4096", "chunked=8192"):
pts = [(r["itl_ms"], r["tok_s_gpu"], r["concurrency"])
for r in results if r["variant"] == variant]
xs, ys, cs = zip(*pts)
plt.plot(xs, ys, "o-", label=variant)
for x, y, c in pts:
plt.annotate(str(c), (x, y), fontsize=7, xytext=(3, 3),
textcoords="offset points")
plt.xlabel("Inter-token latency (ms/token) → worse")
plt.ylabel("Throughput (tokens/s/GPU) → better")
plt.title("Pareto frontier: sweep variants (points labeled by concurrency)")
plt.legend(); plt.grid(alpha=.3); plt.tight_layout(); plt.show()

section("9. Next steps on a real cluster")
print(textwrap.dedent("""
make setup ARCH=aarch64|x86_64
srtctl preflight -f my-disagg.yaml
srtctl apply -f my-disagg.yaml
srtctl apply -f sweep.yaml
srtctl monitor
uv run streamlit run analysis/dashboard/app.py
srtctl diff runA runB
Logs land in outputs/{JOB_ID}/logs/; analysis/srtlog parses them
(NodeAnalyzer, RunLoader) for programmatic post-processing.
Reproducibility tip (srtctl also prints this in dry-run): add an
identity: block to your recipe — HF model repo + revision, container
image URI, and framework versions — so srtctl can verify the runtime
matches your declaration at job start.
"""))
print("✅ Tutorial complete.")
