สร้างเวิร์กโฟลว์ End-to-End OCR ด้วย Unlimited-OCR จาก Baidu รองรับ PDF หลายหน้าและความละเอียดสูง

import subprocess, sys
def pip_install(*pkgs):
    subprocess.check_call([sys.executable, "-m", "pip", "install", "-q", *pkgs])

print(">> Installing dependencies (1-2 min)...")
pip_install(
    "transformers==4.57.1",
    "Pillow",
    "matplotlib",
    "einops",
    "addict",
    "easydict",
    "pymupdf",
    "psutil",
    "accelerate",
)
print(">> Done.")

import os
import torch
from transformers import AutoModel, AutoTokenizer

assert torch.cuda.is_available(), (
    "No GPU detected! In Colab: Runtime -> Change runtime type -> GPU."
)
gpu_name = torch.cuda.get_device_name(0)
print(f">> GPU: {gpu_name}")

use_bf16 = torch.cuda.is_bf16_supported()
DTYPE = torch.bfloat16 if use_bf16 else torch.float16
print(f">> Using dtype: {DTYPE}")

MODEL_NAME = "baidu/Unlimited-OCR"
print(">> Downloading model (~6 GB for 3B params in BF16). First run takes a while...")
tokenizer = AutoTokenizer.from_pretrained(MODEL_NAME, trust_remote_code=True)
model = AutoModel.from_pretrained(
    MODEL_NAME,
    trust_remote_code=True,
    use_safetensors=True,
    torch_dtype=DTYPE,
)
model = model.eval().cuda()
print(">> Model loaded and moved to GPU.")

from PIL import Image, ImageDraw, ImageFont
import textwrap

os.makedirs("inputs", exist_ok=True)
os.makedirs("outputs/single_gundam", exist_ok=True)
os.makedirs("outputs/single_base", exist_ok=True)
os.makedirs("outputs/multi_page", exist_ok=True)

def load_font(size):
    for path in [
        "/usr/share/fonts/truetype/dejavu/DejaVuSans-Bold.ttf",
        "/usr/share/fonts/truetype/dejavu/DejaVuSans.ttf",
    ]:
        if os.path.exists(path):
            return ImageFont.truetype(path, size)
    return ImageFont.load_default()

def make_sample_page(path, page_no):
    W, H = 1240, 1754
    img = Image.new("RGB", (W, H), "white")
    d = ImageDraw.Draw(img)
    title_f, head_f, body_f = load_font(48), load_font(34), load_font(26)

d.text((80, 70), f"Quarterly Operations Report — Page {page_no}",
           fill="black", font=title_f)
    d.line([(80, 145), (W - 80, 145)], fill="black", width=3)

body = (
        "This document demonstrates Unlimited-OCR's one-shot long-horizon "
        "parsing. The model reads an entire page — headings, paragraphs, "
        "and tables — and emits structured text in a single decoding pass. "
        "Unlike classic OCR pipelines, no separate layout-analysis stage "
        "is required."
    )
    y = 190
    for line in textwrap.wrap(body, width=72):
        d.text((80, y), line, fill="black", font=body_f)
        y += 40

y += 30
    d.text((80, y), f"Table {page_no}: Regional Revenue (USD, millions)",
           fill="black", font=head_f)
    y += 60

rows = [
        ["Region", "Q1", "Q2", "Q3"],
        ["North", "12.4", "13.1", "15.0"],
        ["South", "9.8", "10.2", "11.7"],
        ["East", "14.3", "13.9", "16.2"],
        ["West", "11.1", "12.5", "12.9"],
    ]
    col_w, row_h, x0 = 260, 56, 80
    for r, row in enumerate(rows):
        for c, cell in enumerate(row):
            x = x0 + c * col_w
            d.rectangle([x, y, x + col_w, y + row_h], outline="black", width=2)
            d.text((x + 14, y + 12), cell, fill="black", font=body_f)
        y += row_h

y += 50
    footer = (
        f"Note {page_no}: Figures are illustrative. Multi-page mode stitches "
        "context across pages, so cross-page references remain coherent."
    )
    for line in textwrap.wrap(footer, width=72):
        d.text((80, y), line, fill="black", font=body_f)
        y += 40

img.save(path)
    return path

IMAGE_PATH = make_sample_page("inputs/sample_page_1.png", 1)
PAGE_2 = make_sample_page("inputs/sample_page_2.png", 2)
PAGE_3 = make_sample_page("inputs/sample_page_3.png", 3)

print(f">> Sample pages written: {IMAGE_PATH}, {PAGE_2}, {PAGE_3}")

import matplotlib.pyplot as plt
plt.figure(figsize=(6, 8))
plt.imshow(Image.open(IMAGE_PATH))
plt.axis("off")
plt.title("Input document (page 1)")
plt.show()
``` เพื่อให้เห็นประสิทธิภาพการทำงาน เราได้จำลองหน้าเอกสาร 3 หน้าที่มีทั้งข้อความ ตาราง และเชิงอรรถโดยใช้ไลบรารี PIL เพื่อทดสอบความสามารถในการประมวลผลเลย์เอาต์ที่ซับซ้อน และพรีวิวผลลัพธ์หน้าแรกผ่าน Matplotlib ก่อนเข้าสู่ขั้นตอน OCR จริง

```python
print("\n" + "=" * 76)
print("STEP 4: Single image — GUNDAM mode (tiled, high detail)")
print("=" * 76)

model.infer(
    tokenizer,
    prompt="<image>document parsing.",
    image_file=IMAGE_PATH,
    output_path="outputs/single_gundam",
    base_size=1024,
    image_size=640,
    crop_mode=True,
    max_length=32768,
    no_repeat_ngram_size=35,
    ngram_window=128,
    save_results=True,
)

print("\n" + "=" * 76)
print("STEP 5: Single image — BASE mode (single view, faster)")
print("=" * 76)

model.infer(
    tokenizer,
    prompt="<image>document parsing.",
    image_file=IMAGE_PATH,
    output_path="outputs/single_base",
    base_size=1024,
    image_size=1024,
    crop_mode=False,
    max_length=32768,
    no_repeat_ngram_size=35,
    ngram_window=128,
    save_results=True,
)

print("\n" + "=" * 76)
print("STEP 6: Multi-page / PDF parsing")
print("=" * 76)

import tempfile
import fitz

def pdf_to_images(pdf_path, dpi=300):
    """Rasterize every PDF page to a PNG; return the list of image paths."""
    doc = fitz.open(pdf_path)
    tmp_dir = tempfile.mkdtemp(prefix="pdf_ocr_")
    mat = fitz.Matrix(dpi / 72, dpi / 72)
    paths = []
    for i, page in enumerate(doc):
        out = os.path.join(tmp_dir, f"page_{i + 1:04d}.png")
        page.get_pixmap(matrix=mat).save(out)
        paths.append(out)
    doc.close()
    return paths

SAMPLE_PDF = "inputs/sample_doc.pdf"
pdf = fitz.open()
for p in [IMAGE_PATH, PAGE_2, PAGE_3]:
    img_doc = fitz.open(p)
    rect = img_doc[0].rect
    pdf_bytes = img_doc.convert_to_pdf()
    img_pdf = fitz.open("pdf", pdf_bytes)
    page = pdf.new_page(width=rect.width, height=rect.height)
    page.show_pdf_page(rect, img_pdf, 0)
pdf.save(SAMPLE_PDF)
pdf.close()
print(f">> Built sample PDF: {SAMPLE_PDF}")

page_images = pdf_to_images(SAMPLE_PDF, dpi=300)
print(f">> Rasterized {len(page_images)} pages")

model.infer_multi(
    tokenizer,
    prompt="<image>Multi page parsing.",
    image_files=page_images,
    output_path="outputs/multi_page",
    image_size=1024,
    max_length=32768,
    no_repeat_ngram_size=35,
    ngram_window=1024,
    save_results=True,
)

print("\n" + "=" * 76)
print("STEP 7: Saved outputs")
print("=" * 76)

TEXT_EXTS = {".txt", ".md", ".mmd", ".json"}

def show_outputs(root):
    print(f"\n--- {root} ---")
    if not os.path.isdir(root):
        print(" (no output directory found)")
        return
    for dirpath, _, files in os.walk(root):
        for fn in sorted(files):
            fp = os.path.join(dirpath, fn)
            size = os.path.getsize(fp)
            print(f"  {fp} ({size:,} bytes)")
            if os.path.splitext(fn)[1].lower() in TEXT_EXTS:
                with open(fp, "r", encoding="utf-8", errors="replace") as f:
                    content = f.read()
                    preview = content[:1500]
                    print("    " + "-" * 60)
                    print("\n".join("    | " + ln for ln in preview.splitlines()))
                    if len(content) > 1500:
                        print(f"    | ... [{len(content) - 1500:,} more chars]")
                    print("    " + "-" * 60)

for out_dir in ["outputs/single_gundam", "outputs/single_base", "outputs/multi_page"]:
    show_outputs(out_dir)

print("""
============================================================================
DONE — CHEAT SHEET
============================================================================
Single image, dense/small text .... infer(), gundam (640 + crop_mode=True)
Single image, clean print ......... infer(), base (1024, crop_mode=False)
Multi-page or PDF ................. infer_multi(), image_size=1024,
                                    ngram_window=1024
Long documents .................... keep max_length=32768 and the
                                    no_repeat_ngram settings — they prevent
                                    degeneration on long outputs.
Your own files .................... upload via Colab sidebar, point
                                    image_file / pdf_to_images() at them.
============================================================================
""")
