เจาะลึก cuDNN Graph API: ปรับแต่ง Fusion และ Autotuning ขั้นสูง

import os
import sys
import glob
import math
import time
import ctypes
import traceback
import subprocess
RESULTS = {}
def banner(title):
print("\n" + "=" * 78)
print(title)
print("=" * 78)
def section(name):
def wrap(fn):
def run(*a, **kw):
banner(name)
try:
out = fn(*a, **kw)
RESULTS[name] = out if isinstance(out, str) else "ok"
return out
except Exception as e:
RESULTS[name] = f"SKIPPED / FAILED -> {type(e).__name__}: {e}"
print(f"\n[!] {name} did not complete: {type(e).__name__}: {e}")
traceback.print_exc(limit=3)
return None
return run
return wrap
banner("0. Install nvidia-cudnn-frontend and locate libcudnn")
subprocess.run(
[sys.executable, "-m", "pip", "install", "-q", "nvidia-cudnn-frontend"],
check=True,
)
import torch
assert torch.cuda.is_available(), "No GPU. Runtime -> Change runtime type -> GPU."
torch.backends.cudnn.enabled = True
_ = torch.nn.functional.conv2d(
torch.randn(1, 1, 8, 8, device="cuda"), torch.randn(1, 1, 3, 3, device="cuda")
)
torch.cuda.synchronize()
try:
import nvidia.cudnn
_libdir = os.path.join(os.path.dirname(nvidia.cudnn.__file__), "lib")
os.environ["CUDNN_PATH"] = os.path.dirname(nvidia.cudnn.__file__)
os.environ["LD_LIBRARY_PATH"] = _libdir + ":" + os.environ.get("LD_LIBRARY_PATH", "")
for _so in sorted(glob.glob(os.path.join(_libdir, "libcudnn*.so*"))):
try:
ctypes.CDLL(_so, mode=ctypes.RTLD_GLOBAL)
except OSError:
pass
except Exception as _e:
print(f" (no pip cuDNN package found, relying on system cuDNN: {_e})")
import cudnn
print(" cuDNN frontend imported successfully.")
banner("1. Environment")
DEV = torch.device("cuda")
MAJOR, MINOR = torch.cuda.get_device_capability()
SM = MAJOR * 10 + MINOR
CUDNN_VER = cudnn.backend_version()
print(f" GPU : {torch.cuda.get_device_name(0)}")
print(f" Compute capability : sm_{SM}")
print(f" Torch / CUDA : {torch.__version__} / {torch.version.cuda}")
print(f" cuDNN backend : {CUDNN_VER}")
try:
print(f" cuDNN version str : {cudnn.backend_version_string()}")
except Exception:
pass
DTYPE = torch.bfloat16 if SM >= 80 else torch.float16
HAS_SDPA = SM >= 80
print(f" Working dtype : {DTYPE}")
print(f" Fused SDPA usable : {HAS_SDPA}")
HANDLE = cudnn.create_handle()
TORCH2CUDNN = {
torch.float16: cudnn.data_type.HALF,
torch.bfloat16: cudnn.data_type.BFLOAT16,
torch.float32: cudnn.data_type.FLOAT,
torch.int32: cudnn.data_type.INT32,
torch.int64: cudnn.data_type.INT64,
torch.int8: cudnn.data_type.INT8,
torch.uint8: cudnn.data_type.UINT8,
}
def tensor_of(graph, t, name):
return graph.tensor(
name=name,
dim=list(t.size()),
stride=list(t.stride()),
data_type=TORCH2CUDNN[t.dtype],
)
def scalar_of(graph, name):
return graph.tensor(
name=name,
dim=[1, 1, 1],
stride=[1, 1, 1],
data_type=cudnn.data_type.FLOAT,
is_pass_by_value=True,
)
def build(graph, heur=None, policy=None):
heur = heur or [cudnn.heur_mode.A, cudnn.heur_mode.FALLBACK]
graph.validate()
graph.build_operation_graph()
graph.create_execution_plans(heur)
graph.check_support()
if policy is None:
graph.build_plans()
else:
graph.build_plans(policy)
return graph
def workspace_for(graph):
n = graph.get_workspace_size()
return torch.empty(max(n, 1), device=DEV, dtype=torch.uint8)
def bench(fn, warmup=10, iters=50):
for _ in range(warmup):
fn()
torch.cuda.synchronize()
s, e = torch.cuda.Event(True), torch.cuda.Event(True)
s.record()
for _ in range(iters):
fn()
e.record()
torch.cuda.synchronize()
return s.elapsed_time(e) / iters
def tflops(flops, ms):
return flops / (ms * 1e-3) / 1e12
def report(tag, ms, flops=None):
extra = f" ({tflops(flops, ms):7.2f} TFLOP/s)" if flops else ""
print(f" {tag:<34s} {ms:8.3f} ms{extra}")

N, C, H, W = 32, 128, 56, 56
K, R, S = 256, 3, 3
PAD, STR, DIL = 1, 1, 1
P = (H + 2 * PAD - DIL * (R - 1) - 1) // STR + 1
Q = (W + 2 * PAD - DIL * (S - 1) - 1) // STR + 1
CONV_FLOPS = 2 * N * K * P * Q * C * R * S
CONV_STATE = {}
@section("2. Fused Conv -> Bias -> ReLU")
def conv_fusion():
x = torch.randn(N, C, H, W, device=DEV, dtype=DTYPE).to(memory_format=torch.channels_last)
w = torch.randn(K, C, R, S, device=DEV, dtype=DTYPE).to(memory_format=torch.channels_last)
b = torch.randn(1, K, 1, 1, device=DEV, dtype=DTYPE)
y = torch.empty(N, K, P, Q, device=DEV, dtype=DTYPE).to(memory_format=torch.channels_last)
g = cudnn.pygraph(
handle=HANDLE,
name="conv_bias_relu",
io_data_type=TORCH2CUDNN[DTYPE],
intermediate_data_type=cudnn.data_type.FLOAT,
compute_data_type=cudnn.data_type.FLOAT,
)
X = tensor_of(g, x, "X")
Wt = tensor_of(g, w, "W")
Bt = tensor_of(g, b, "bias")
conv = g.conv_fprop(
image=X, weight=Wt,
padding=[PAD, PAD], stride=[STR, STR], dilation=[DIL, DIL],
compute_data_type=cudnn.data_type.FLOAT,
)
biased = g.bias(input=conv, bias=Bt)
Y = g.relu(input=biased)
Y.set_output(True).set_data_type(TORCH2CUDNN[DTYPE])
Y.set_dim(list(y.size())).set_stride(list(y.stride()))
t0 = time.perf_counter()
build(g)
build_ms = (time.perf_counter() - t0) * 1e3
ws = workspace_for(g)
pack = {X: x, Wt: w, Bt: b, Y: y}
g.execute(pack, ws)
torch.cuda.synchronize()
ref = torch.relu(torch.nn.functional.conv2d(x, w, bias=b.flatten(), padding=PAD))
err = (y.float() - ref.float()).abs().max().item()
scale = ref.float().abs().max().item()
print(f" problem : N{N} C{C} {H}x{W} -> K{K} {R}x{S} ({DTYPE})")
print(f" build : {build_ms:.1f} ms workspace: {ws.numel()/1024:.1f} KiB")
print(f" max |err|: {err:.4f} (ref max {scale:.2f}, rel {err/max(scale,1e-9):.2e})")
assert err / max(scale, 1e-9) < 5e-2, "numerical mismatch vs PyTorch"
ms_cudnn = bench(lambda: g.execute(pack, ws))
ms_torch = bench(lambda: torch.relu(
torch.nn.functional.conv2d(x, w, bias=b.flatten(), padding=PAD)))
print()
report("cuDNN FE (single fused kernel)", ms_cudnn, CONV_FLOPS)
report("PyTorch (conv+bias, then relu)", ms_torch, CONV_FLOPS)
print(f" speedup: {ms_torch/ms_cudnn:.2f}x")
CONV_STATE.update(graph=g, pack=pack, ws=ws, x=x, w=w, b=b, y=y)
return f"{ms_cudnn:.3f} ms, {tflops(CONV_FLOPS, ms_cudnn):.1f} TFLOP/s"
conv_fusion()

@section("3. Autotuning: build ALL plans, time each engine config")
def autotune():
x, w, b, y = CONV_STATE["x"], CONV_STATE["w"], CONV_STATE["b"], CONV_STATE["y"]
g = cudnn.pygraph(
handle=HANDLE, name="conv_autotune",
io_data_type=TORCH2CUDNN[DTYPE],
intermediate_data_type=cudnn.data_type.FLOAT,
compute_data_type=cudnn.data_type.FLOAT,
)
X = tensor_of(g, x, "X")
Wt = tensor_of(g, w, "W")
Bt = tensor_of(g, b, "bias")
Y = g.relu(input=g.bias(
input=g.conv_fprop(image=X, weight=Wt, padding=[PAD, PAD],
stride=[STR, STR], dilation=[DIL, DIL],
compute_data_type=cudnn.data_type.FLOAT),
bias=Bt))
Y.set_output(True).set_data_type(TORCH2CUDNN[DTYPE])
Y.set_dim(list(y.size())).set_stride(list(y.stride()))
g.validate()
g.build_operation_graph()
g.create_execution_plans([cudnn.heur_mode.A, cudnn.heur_mode.B, cudnn.heur_mode.FALLBACK])
g.check_support()
g.build_plans(cudnn.build_plan_policy.ALL)
n_plans = g.get_execution_plan_count()
print(f" {n_plans} candidate engine configs survived support checks\n")
pack = {X: x, Wt: w, Bt: b, Y: y}
timings = []
for i in range(n_plans):
try:
g.build_plan_at_index(i)
ws_sz = max(g.get_workspace_size_plan_at_index(i), 1)
ws = torch.empty(ws_sz, device=DEV, dtype=torch.uint8)
ms = bench(lambda: g.execute_plan_at_index(pack, ws, i), warmup=3, iters=15)
timings.append((ms, i, ws_sz))
print(f" plan {i:>3d}: {ms:8.3f} ms "
f"{tflops(CONV_FLOPS, ms):7.2f} TFLOP/s ws={ws_sz/1024:8.1f} KiB")
except Exception as e:
print(f" plan {i:>3d}: unusable ({type(e).__name__})")
assert timings, "no plan executed"
timings.sort()
best_ms, best_i, best_ws = timings[0]
worst_ms = timings[-1][0]
print(f"\n fastest = plan {best_i} @ {best_ms:.3f} ms")
print(f" slowest = {worst_ms:.3f} ms -> {worst_ms/best_ms:.1f}x spread across engines")
print(" Takeaway: heuristics are good, but for a hot shape you ship the")
print(" autotuned index (or the serialized plan from section 6).")
return f"best plan {best_i} @ {best_ms:.3f} ms ({worst_ms/best_ms:.1f}x spread)"
autotune()

@section("4. Matmul -> scale -> bias -> activation -> AMAX")
def matmul_epilogue():
Bsz, M, Kd, Nd = 16, 512, 1024, 512
MM_FLOPS = 2 * Bsz * M * Nd * Kd
a = torch.randn(Bsz, M, Kd, device=DEV, dtype=DTYPE)
bm = torch.randn(Bsz, Kd, Nd, device=DEV, dtype=DTYPE)
bias = torch.randn(1, 1, Nd, device=DEV, dtype=DTYPE)
out = torch.empty(Bsz, M, Nd, device=DEV, dtype=DTYPE)
amax = torch.empty(1, 1, 1, device=DEV, dtype=torch.float32)
alpha_val = 0.125
alpha = torch.full((1, 1, 1), alpha_val, dtype=torch.float32)
g = cudnn.pygraph(
handle=HANDLE, name="matmul_epilogue",
io_data_type=TORCH2CUDNN[DTYPE],
intermediate_data_type=cudnn.data_type.FLOAT,
compute_data_type=cudnn.data_type.FLOAT,
)
A = tensor_of(g, a, "A")
Bt = tensor_of(g, bm, "B")
BIAS = tensor_of(g, bias, "bias")
ALPHA = scalar_of(g, "alpha")
acc = g.matmul(A=A, B=Bt, compute_data_type=cudnn.data_type.FLOAT)
scaled = g.mul(a=acc, b=ALPHA)
biased = g.bias(input=scaled, bias=BIAS)
act_name = "relu"
if hasattr(g, "gelu"):
try:
act = g.gelu(input=biased)
act_name = "gelu"
except Exception:
act = g.relu(input=biased)
else:
act = g.relu(input=biased)
print(f" activation used: {act_name}")
OUT = act
OUT.set_output(True).set_data_type(TORCH2CUDNN[DTYPE])
have_amax = True
try:
AMAX = g.reduction(input=act, mode=cudnn.reduction_mode.AMAX,
compute_data_type=cudnn.data_type.FLOAT)
AMAX.set_output(True).set_data_type(cudnn.data_type.FLOAT)
AMAX.set_dim([1, 1, 1]).set_stride([1, 1, 1])
except Exception as e:
have_amax = False
print(f" (AMAX reduction unavailable here: {e})")
build(g)
ws = workspace_for(g)
pack = {A: a, Bt: bm, BIAS: bias, ALPHA: alpha, OUT: out}
if have_amax:
pack[AMAX] = amax
g.execute(pack, ws)
torch.cuda.synchronize()
ref = torch.matmul(a.float(), bm.float()) * alpha_val + bias.float()
ref = torch.nn.functional.gelu(ref) if act_name == "gelu" else torch.relu(ref)
rel = ((out.float() - ref).abs().max() / ref.abs().max()).item()
print(f" shape : ({Bsz},{M},{Kd}) x ({Bsz},{Kd},{Nd})")
print(f" rel err : {rel:.2e}")
if have_amax:
print(f" fused AMAX {amax.item():.4f} vs torch {ref.abs().max().item():.4f}")
ms = bench(lambda: g.execute(pack, ws))
def torch_ref():
r = torch.baddbmm(bias.expand(Bsz, M, Nd), a, bm, beta=1.0, alpha=alpha_val)
r = torch.nn.functional.gelu(r) if act_name == "gelu" else torch.relu(r)
return r.abs().amax()
ms_t = bench(torch_ref)
print()
report("cuDNN FE (one fused kernel)", ms, MM_FLOPS)
report("PyTorch (bmm + act + amax)", ms_t, MM_FLOPS)
print(f" speedup: {ms_t/ms:.2f}x -- the win is the epilogue traffic, not the GEMM")
return f"{ms:.3f} ms, {tflops(MM_FLOPS, ms):.1f} TFLOP/s, {ms_t/ms:.2f}x vs torch"
matmul_epilogue()

@section("5. SDPA (Flash Attention) with causal masking")
def sdpa_demo():
if not HAS_SDPA:
raise RuntimeError(f"fused SDPA needs SM80+ (Ampere), this GPU is sm_{SM}")
b, h, s, d = 4, 16, 1024, 64
scale = 1.0 / math.sqrt(d)
SDPA_FLOPS = 4 * b * h * s * s * d * 0.5
q = torch.randn(b, h, s, d, device=DEV, dtype=DTYPE)
k = torch.randn(b, h, s, d, device=DEV, dtype=DTYPE)
v = torch.randn(b, h, s, d, device=DEV, dtype=DTYPE)
o = torch.empty(b, h, s, d, device=DEV, dtype=DTYPE)
g = cudnn.pygraph(
handle=HANDLE, name="sdpa",
io_data_type=TORCH2CUDNN[DTYPE],
intermediate_data_type=cudnn.data_type.FLOAT,
compute_data_type=cudnn.data_type.FLOAT,
)
Q, Kt, V = tensor_of(g, q, "Q"), tensor_of(g, k, "K"), tensor_of(g, v, "V")
causal = True
try:
O, _stats = g.sdpa(name="sdpa", q=Q, k=Kt, v=V,
is_inference=True, attn_scale=scale, use_causal_mask=True)
except TypeError:
try:
O, _stats = g.sdpa(name="sdpa", q=Q, k=Kt, v=V,
is_inference=True, attn_scale=scale,
diagonal_alignment=cudnn.diagonal_alignment.TOP_LEFT,
right_bound=0)
except Exception:
causal = False
O, _stats = g.sdpa(name="sdpa", q=Q, k=Kt, v=V,
is_inference=True, attn_scale=scale)
print(f" causal masking: {causal}")
O.set_output(True).set_data_type(TORCH2CUDNN[DTYPE])
O.set_dim(list(o.size())).set_stride(list(o.stride()))
build(g)
ws = workspace_for(g)
pack = {Q: q, Kt: k, V: v, O: o}
g.execute(pack, ws)
torch.cuda.synchronize()
ref = torch.nn.functional.scaled_dot_product_attention(q, k, v, is_causal=causal, scale=scale)
rel = ((o.float() - ref.float()).abs().max() / ref.float().abs().max()).item()
print(f" shape : b{b} h{h} s{s} d{d} workspace {ws.numel()/1024:.1f} KiB")
print(f" rel err : {rel:.2e}")
ms = bench(lambda: g.execute(pack, ws))
ms_t = bench(lambda: torch.nn.functional.scaled_dot_product_attention(
q, k, v, is_causal=causal, scale=scale))
print()
report("cuDNN FE SDPA", ms, SDPA_FLOPS)
report("torch SDPA (backend's choice)", ms_t, SDPA_FLOPS)
print(" Note: torch may already be dispatching to cuDNN or FlashAttention,")
print(" so parity here is the expected, healthy outcome.")
return f"{ms:.3f} ms, {tflops(SDPA_FLOPS, ms):.1f} TFLOP/s"
sdpa_demo()
@section("6. Serialize a built graph, reload it, execute by UID")
def serialization():
Bsz, M, Kd, Nd = 8, 256, 512, 256
a = torch.randn(Bsz, M, Kd, device=DEV, dtype=DTYPE)
bm = torch.randn(Bsz, Kd, Nd, device=DEV, dtype=DTYPE)
out = torch.empty(Bsz, M, Nd, device=DEV, dtype=DTYPE)
UID_A, UID_B, UID_C = 1, 2, 3
g = cudnn.pygraph(
handle=HANDLE, name="serializable_mm",
io_data_type=TORCH2CUDNN[DTYPE],
intermediate_data_type=cudnn.data_type.FLOAT,
compute_data_type=cudnn.data_type.FLOAT,
)
A = tensor_of(g, a, "A").set_uid(UID_A)
Bt = tensor_of(g, bm, "B").set_uid(UID_B)
C = g.matmul(A=A, B=Bt, compute_data_type=cudnn.data_type.FLOAT)
C.set_output(True).set_data_type(TORCH2CUDNN[DTYPE]).set_uid(UID_C)
t0 = time.perf_counter()
build(g)
cold_ms = (time.perf_counter() - t0) * 1e3
blob = g.serialize()
print(f" cold build : {cold_ms:.1f} ms")
print(f" serialized plan : {len(blob)} bytes (cache this to disk / ship it)")
t0 = time.perf_counter()
g2 = cudnn.pygraph()
try:
g2.deserialize(HANDLE, blob)
except TypeError:
g2.deserialize(blob)
warm_ms = (time.perf_counter() - t0) * 1e3
print(f" deserialize : {warm_ms:.1f} ms -> {cold_ms/max(warm_ms,1e-6):.1f}x faster startup")
ws = torch.empty(max(g2.get_workspace_size(), 1), device=DEV, dtype=torch.uint8)
g2.execute({UID_A: a, UID_B: bm, UID_C: out}, ws, handle=HANDLE)
torch.cuda.synchronize()
ref = torch.bmm(a.float(), bm.float())
rel = ((out.float() - ref).abs().max() / ref.abs().max()).item()
print(f" rel err after reload: {rel:.2e}")
return f"{len(blob)} B blob, reload {cold_ms/max(warm_ms,1e-6):.1f}x faster than rebuild"
serialization()

@section("7. Dynamic shapes with a shared kernel cache")
def dynamic_shapes():
kc = cudnn.create_kernel_cache()
def make(n):
x = torch.randn(n, 64, 32, 32, device=DEV, dtype=DTYPE).to(memory_format=torch.channels_last)
w = torch.randn(64, 64, 3, 3, device=DEV, dtype=DTYPE).to(memory_format=torch.channels_last)
y = torch.empty(n, 64, 32, 32, device=DEV, dtype=DTYPE).to(memory_format=torch.channels_last)
g = cudnn.pygraph(
handle=HANDLE, name=f"dyn_{n}",
io_data_type=TORCH2CUDNN[DTYPE],
intermediate_data_type=cudnn.data_type.FLOAT,
compute_data_type=cudnn.data_type.FLOAT,
kernel_cache=kc,
is_dynamic_shape_enabled=True,
)
X, Wt = tensor_of(g, x, "X"), tensor_of(g, w, "W")
Y = g.conv_fprop(image=X, weight=Wt, padding=[1, 1], stride=[1, 1],
dilation=[1, 1], compute_data_type=cudnn.data_type.FLOAT)
Y.set_output(True).set_data_type(TORCH2CUDNN[DTYPE])
Y.set_dim(list(y.size())).set_stride(list(y.stride()))
t0 = time.perf_counter()
build(g)
ms = (time.perf_counter() - t0) * 1e3
ws = workspace_for(g)
g.execute({X: x, Wt: w, Y: y}, ws)
torch.cuda.synchronize()
return ms
times = [(n, make(n)) for n in (8, 16, 24, 32)]
for n, ms in times:
print(f" batch {n:>3d}: build {ms:7.1f} ms")
first, rest = times[0][1], [m for _, m in times[1:]]
print(f"\n first shape {first:.1f} ms, later shapes avg {sum(rest)/len(rest):.1f} ms")
print(" The cache lets shape-variant graphs reuse an already-JIT'd kernel,")
print(" which is what keeps variable batch/seqlen serving out of rebuild hell.")
return f"first {first:.0f} ms vs subsequent {sum(rest)/len(rest):.0f} ms"
dynamic_shapes()
@section("8. CUDA Graph capture around a cuDNN execution plan")
def cuda_graph_capture():
if not CONV_STATE:
raise RuntimeError("section 2 did not run, nothing to capture")
g, pack, ws = CONV_STATE["graph"], CONV_STATE["pack"], CONV_STATE["ws"]
eager_ms = bench(lambda: g.execute(pack, ws))
side = torch.cuda.Stream()
side.wait_stream(torch.cuda.current_stream())
with torch.cuda.stream(side):
cudnn.set_stream(handle=HANDLE, stream=side.cuda_stream)
for _ in range(3):
g.execute(pack, ws, handle=HANDLE)
torch.cuda.current_stream().wait_stream(side)
torch.cuda.synchronize()
cg = torch.cuda.CUDAGraph()
with torch.cuda.graph(cg):
cudnn.set_stream(handle=HANDLE, stream=torch.cuda.current_stream().cuda_stream)
g.execute(pack, ws, handle=HANDLE)
cudnn.set_stream(handle=HANDLE, stream=torch.cuda.current_stream().cuda_stream)
replay_ms = bench(lambda: cg.replay())
report("plain execute()", eager_ms)
report("cuda graph replay()", replay_ms)
print(f" launch overhead removed: {(eager_ms-replay_ms)*1e3:.1f} us/iter")
print(" Pointers are frozen at capture time -- reuse the same buffers and")
print(" copy new data into them, or re-capture.")
return f"{eager_ms:.3f} -> {replay_ms:.3f} ms via replay"
cuda_graph_capture()
banner("SUMMARY")
for name, res in RESULTS.items():
print(f" {name:<58s} {res}")
print("""
Where to go next
- samples/python in the repo: FP8/MXFP8 attention, paged KV cache, MoE grouped GEMM
- python/cudnn/: the open-sourced CuTe DSL kernels (SDPA, grouped GEMM + SwiGLU,
block-sparse and native sparse attention) you can read and modify
- debugging: CUDNN_FRONTEND_LOG_INFO=1 and CUDNN_FRONTEND_LOG_FILE=stdout
(use level 10 during CUDA graph capture -- level 1 dumps tensors and is not
capture-safe)
""")
